Summary of Contents for AV Access 4KSP14-L
- Page 1 4KSP14-L 4K HDMI Splitter 1x4 User Manual...
- Page 3 Disclaimers The information in this manual has been carefully checked and is believed to be accurate. AV Access Technology Limited assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use.
- Page 4 Important Safety Instructions Do not expose this device to rain, moisture, dripping or splashing. No objects filled with liquids, such as vases, shall be placed on the device. Do not install or place this unit in a bookcase, built-in cabinet, or in ...
-
Page 5: Table Of Contents
Overview Table of Contents Overview ....................... 2 Package Contents ........................3 Panel ............................4 Installation Instructions ..................6 EDID Management ....................7 Specification ......................8 Warranty ....................... 9 www.avaccess.com... -
Page 6: Overview
Overview Overview 4KSP14-L is a 1x4 splitter for HDMI with Ultra HD 4K support. It reliably distributes one HDMI source signal up to four HDMI outputs. It supports HDMI 1.4a specification features including data rates up to 10.2 Gbps, 12-bit Deep Color, 3D, Lip Sync, and HD lossless Audio/Video formats. -
Page 7: Package Contents
Overview Package Contents Before you start the installation of the product, please check the package contents: 1 x Splitter 4KSP14-L 1 x USB-to-Micro USB Cable 2 x Mounting Ear 1 x User Manual www.avaccess.com... - Page 8 AV Access Technology Limited V1.0.9...
-
Page 9: Panel
Overview Panel Top Panel ID Name Description ON: The splitter is on. Power LED OFF: The splitter is off. ON: The correspondingly numbered output 1~4 is OUTPUT connected to a display device. LED 1~4 OFF: No display device is connected. ON: Both source device and display device are connected. - Page 10 Overview Front Panel Name Description INPUT Port Connects to an HDMI source device OUTPUT Port 1~4 Connects to HDMI display devices Rear Panel Name Description Power Connector Connects to power www.avaccess.com...
-
Page 11: Installation Instructions
Installation Instructions Installation Instructions Connect an HDMI source device (such as a Blu-Ray, games console, media server etc.) to the input port of the splitter using quality HDMI cables. Connect four HDMI display devices (LED/LCD display or projector) to the output ports of the splitter. Connect the Micro USB end of the USB-to-Micro USB cable to the device, and connect the USB end to any USB power source, such as TV, computer, or USB power adapter. -
Page 12: Edid Management
The 4KSP14-L supports EDID mixing function. When connected to multiple monitors, the device will compare the EDID of displays and output the minimum timing. E.g., when a 1080p and a 4k TV access at the same time, the output is 1080p. -
Page 13: Specification
Specification Specification Technical Input / Output 1 x HDMI IN, 4 x HDMI OUT Input / Output Signal Type HDMI 1.4a, 3D, DVI 1.0, HDCP 1.4 4096 x 2160@24Hz, 3840 x 2160@30Hz, Input / Output Resolution 1920x1080@30/60Hz, 1280x720@60Hz, Support 720x576@30/60Hz, 640x480@30/60Hz Maximum Data Rate 10.2 Gpbs Maximum Pixel Clock... -
Page 14: Warranty
The warranty has expired. The defects are caused by the fact that the product is repaired, dismantled or altered by anyone that is not from an AV Access Technology Limited authorized service partner. The defects are caused by the fact that the product is used or handled improperly, roughly or not as instructed in the applicable User Guide.
