- Page 1 4K HDMI over IP Decoder 4KIP200D User Manual...
- Page 2 Introduction Introduction Overview This product is an AV decoder adopting the latest H.265 compression technology. It supports resolutions up to 3840x2160p@30Hz and can be controlled by VDirector App (IOS/Android/Windows version), allowing users to easily build an IP matrix or a video wall through a tablet/cellphone/PC.
- Page 3 Application Panel Info/Source (2s) Key: Short press to display/stop displaying information of encoder and decoder on screen; press and hold for 2 seconds to link the decoder to another encoder. Application a. 1 – 1: Extender b. 1 – n: Splitter c.
- Page 4 Application App with your iPad. (Note: to get Android version, please visit Google Play Store; to get Windows version, please visit www.avaccess.com) 2) Connect all encoders, decoders and the wireless router to the network switch according to the following diagram shown: 3) Configure the wireless router properly, then connect your iPad to the Wi-Fi network.
- Page 5 Specifications Name Description RX Preview Shows the live preview of current RX assignments. TX List Shows the IP stream's live preview from TX device. Drag a TX from TX list over this button means the switching To All Screens of this TX to all RX devices in RX list, including video walls. Display On: Turn on all RXs' displays.
- Page 6 The warranty has expired. The defects are caused by the fact that the product is repaired, dismantled or altered by anyone that is not from an AV Access Technology Limited authorized service partner. The defects are caused by the fact that the product is used or handled improperly, roughly or not as instructed in the applicable User Guide.
