HDIP100E & HDIP100D
1080P HDMI over IP Encoder & Decoder
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDIP100E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AV Access HDIP100E

  • Page 1 HDIP100E & HDIP100D 1080P HDMI over IP Encoder & Decoder User Manual...
  • Page 2 Offenders will be held liable for payment of damages. All rights created by patent grant or registration of a utility model or design patent are reserved. Copyright ©2016 AV Access Technology Limited All rights reserved.
  • Page 3 1. Application (a) 1-1: Extender Encoder Decoder HDMI RS232 HDMI RS232 Projector Laptop (b) 1 - n : Splitter Switch Encoder Decoder HDMI HDMI Decoder HDMI DVD Player (c) m - n: Matrix/Video Wall To configure matrix and video wall, perform the following: (1) Scan the QR code or search "VDirector"...
  • Page 4 No. Name Description Logo This logo can be changed to a new one. System Click this button to enter system configuration page for the Configuration functions: 1) Naming and Sequencing; 2) Video Wall Settings; 3) Button Advanced Settings; 4) System Information. RX List Shows the list of online RX devices, including single device and devices for video walls.
  • Page 5 Video Encoder Decoder Output Resolutions up to 1080P@60Hz up to 1080P@60Hz Video Protocol H.265 Video Compression Audio Encoder Decoder Input Port 1 x HDMI 1 x LAN Output Port 1 x LAN, 1 x Line Out 1 x HDMI, 1 x Line Out Audio Format MPEG4-AAC and LPCM Stereo Control...
  • Page 6 (2) Why can't the VDirector find online devices? Ensure the network switch's broadcasting function is not disabled intentionally. (3) Do the encoder and decoder support RS232 routing? Yes. RS232 and audio routing will always follow video routing. (4) Is it also available to configure video wall in the 1-n application? Yes.
  • Page 7 2. The warranty has expired. 3. The defects are caused by the fact that the product is repaired, dismantled or altered by anyone that is not from an AV Access Technology Limited authorized service partner. The defects are caused by the fact that the product is used or handled improperly, roughly or not as instructed in the applicable User Guide.
  • Page 8 AV Access Technology Limited V1.0.0...
