- Page 1 1080P HDMI over IP Encoder HDIP100E User Manual...
- Page 2 Introduction Introduction Overview HDIP100E is an AV encoder adopting the latest H.265 compression technology. It supports resolutions up to 1080P@60Hz and can be controlled by VDirector App (IOS/Android/Windows version), allowing users to easily build an IP matrix or a video wall through a tablet/cellphone/PC.
- Page 3 Application Panel Power LED Status LED Reset Reset LED Power Audio Out HDMI In RS232 Connector LAN (PoE) Application a. 1 – 1: Extender Encoder Decoder HDMI RS232 HDMI RS232 Projector Laptop b. 1 – n: Splitter Switch Encoder Decoder HDMI HDMI Decoder...
- Page 4 Application visit www.avaccess.com) 2) Connect all encoders, decoders and the wireless router to the network switch according to the following diagram shown: Audio/Video Input Audio/Video Output Switch Encoder DVD Player Decoder HDMI HDMI Laptop Encoder HDMI Decoder HDMI Control iPad Wireless Router (VDirector) 3) Configure the wireless router properly, and then connect your...
- Page 5 Specifications Name Description RX Preview Shows the live preview of current RX assignments. TX List Shows the IP stream's live preview from TX device. Drag a TX from TX list over this button means the switching of To All Screens this TX to all RX devices in RX list, including video walls.
- Page 6 The warranty has expired. The defects are caused by the fact that the product is repaired, dismantled or altered by anyone that is not from an AV Access Technology Limited authorized service partner. The defects are caused by the fact that the product is used or handled improperly, roughly or not as instructed in the applicable User Guide.
