DEMO MANUAL DC2064A

parts list

ITEM QTY REFERENCE
Required Circuit Components
1 24 C1A-C12A, C1B-C12B
2 12 C1G-C12G
3 12 C1H-C12H
4 12 C1R-C12R
5 14 C1K-C12K, C20,C21
6 4 C2, C4, C8, C14
7 1 C7
8 3 C11, C12, C15
9 2 C18, C19
10 2 D23, D24
11 4 D1, D5, D19.D20
12 3 D6, D7, D8
13 12 D1E-D12E
14 2 D12, D13
15 1 D14
16 1 D15
17 2 D21, D22
18 2 D25, D26
19 12 D1F-D12F
20 24 R1C-R12C, R1F-R12F
21 2 R4, R6
22 24 R1G-R12G, R1H-R12H
23 7 R26, R27, R30, R35-R38
24 5 R1, R5, R15-R17
25 2 R13, R14
26 3 R7, R9, R11
27 2 R8, R10
28 2 R51, R52
29 2 R39, R40
30 2 R28, R29
31 1 R53
32 2 R54, R55
33 12 RS1A-RS12A
34 12 RS1B-RS12B
35 12 Q1A-Q12A
36 12 Q1B-Q12B
37 2 Q13,Q14
38 1 Q15
39 1 Q16
40 1 Q17
41 12 T1-T12
42 2 U1,U2
43 1 U3
44 1 U4
45 1 U5
46 1 U8
36
PART DESCRIPTION
CAP.,X5R, 100µF, 6.3V,10%, 1210
CAP.,X7R, 2200pF, 50V, 10% 0402
CAP.,X7R, 470pF, 50V, 10% 0402
CAP.,X7R, 2.2µF, 100V,10%, 1210
CAP.,X7R, 1.0µF, 16V,10%, 0603
CAP, X7R, 0.1µF, 16V, 10% 0402
CAP.,X7R, 0.1µF, 25V,10%, 0603
CAP.,X5R, 1µF, 25V,10%, 0603
CAP.,X7R, 0.22µF, 10V,10%, 0603
SMD, SCHOTTKY, SOD523
SMD, SCHOTTKY, SOD-123F
SMD, SILICON SWITCHING DIODE
DIODE, ZENER, 7.5V, 400MW, SOD323
SMD, SCHOTTKY, 200MW, 100V, SOD-12
SMD, SILICON ZENER, 62V
SMD, SCHOTTKY
DIODE, ZENER, 5.1V,SOD-123
DIODE, ZENER, 5.6V, 400MW, SOD323
DIODE, SUPER BARRIER RECTIFIER, 10A, POWERDI5
RES,CHIP, 5.1Ω, 1/16W, 5%, 0402
RES,CHIP, 6.8Ω, 1/16W, 5%, 0402
RES,CHIP,20Ω,1/16W,5%,0402
RES,CHIP,100Ω,1/16W,5%,0402
RES,CHIP, 1.00M, 1/16W, 5%, 0402
RES, CHIP, 845k, 1/8W, 1%, 0805
RES, CHIP, 15.4k, 1/16W, 1%, 0402
RES, CHIP, 20.5k, 1/16W, 1%, 0402
RES,CHIP,2.0k,1/16W,5%,0402
RES, CHIP, 5.1k, 1/16W, 5%, 0402
RES, CHIP, 10.0k, 1/16W, 5%, 0402
RES, CHIP, 100k, 1/16W, 5%, 0402
RES, CHIP, 20Ω, 1/16W, 5%, 0603
RES, CHIP, 8mΩ, 1W, 1%, 1206
RES, CHIP, 16mΩ, 1W, 1%, 1206
MOSFET, 100V, 0.0087Ω, 60A, POWERPAK-SO8
MOSFET, 100V, 0.058Ω, 25A, POWERPAK-1212-8
MOSFET, 100V, 10Ω, SOT-323
TRANSISTOR,PNP, 60V SOT-23
TRANSISTOR, NPN, 60V SOT-23
MOSFET, P-CHAN, 50V, 4Ω,SOT-23
TRANSFORMER, 1:1, 3.0µH, 10.8A
IC, SMT, BIDIRECTIONAL BATTERY BALANCER
IC, EEPROM 2KBIT, 400KHZ, 8TSSOP
IC, SMT, OP AMP
IC, GATE NAND QUAD 2-PIN 14-SO
IC, SMT, BATTERY MONITOR
MANUFACTURER/PART NUMBER
MURATA, GRM32ER60J107ME20L
MURATA, GRM155R71H222KA01D
MURATA, GRM155R71H471KA01D
TDK, C3225X7R2A225K
MURATA, GRM188R71C105KA12D
MURATA, GRM155R71C104KA88D
AVX, 06033C104KAT2A
TDK, C1608X5R1E105K
MURATA, GRM188R71A224KA01
CENTRAL SEMI, CMOSH-4E
CENTRAL SEMI, CMMSH2-40
VISHAY, RS07J
NXP, PDZ7.5B.115
DIODES INC, BAT46W
CENTRAL SEMI, CMHZ5265B
CENTRAL SEMI, CMSH3-20MA
CENTRAL SEMI, CMHZ4689
NXP, PDZ5.6B.115
DIODES INC, SBR10U200P5
VISHAY, CRCW04025R10JNED
VISHAY, CRCW04026R80JNED
VISHAY, CRCW040220R0JNED
VISHAY, CRCW0402100RJNED
VISHAY, CRCW04021M00JNED
VISHAY, CRCW0805845KFKEA
VISHAY, CRCW040215K4FKED
VISHAY, CRCW040220K5FKED
VISHAY, CRCW04022K00JNED
VISHAY, CRCW04025K10JNED
VISHAY, CRCW040210K0JNED
VISHAY, CRCW0402100KJNED
VISHAY, CRCW060320R0JNED
SUSUMU, PRL1632-R008-F-T1
SUSUMU, PRL1632-R016-F-T1
VISHAY, SiR882DP-T1-GE3
VISHAY, SiS892DN-T1-GE3
DIODES INC, BSS123W-7-F
CENTRAL SEMI, CMPT3906E
CENTRAL SEMI, CMPT3904E
CENTRAL SEMI, CMPDM8002A
WURTH, 750312504
LINEAR, LTC3300ILXE-1#PBF
MICROCHIP TECH. 24LC025-I/ST
LINEAR, LT6004IMS8#PBT
FAIRCHILD, MM74HC00M
LINEAR, LTC6803IG-2#PBF
