PARTS LIST
ITEM QTY REFERENCE
1 1
2 1
3 1
4 1
5 1
6 1
7 1
8 1
9 1
10 1
11 1
12 1
13 1
14 1
15 1
16 6
17 3
18 2
19 1
20 1
21 1
22 1
23 2
24 1
25 1
Note 1. These items are not stuffed (DNI).
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
PCB PCB
C1 CAP 22uF 63V ALUM 8x10.5
C2 CAP 1uF 100V CER, X7R 1206
C3 CAP 0.1uF 100V CER X7R 0603
C4 CAP 47nF 50V CER X7R 0603
C5 CAP MLCC 0603 (Note 1)
C6 CAP 10uF 50V X5R 1206
C7 CAP 1uF 10V X7R 0603
C8 CAP 10nF 50V CER X7R 0603
C9 CAP 4.7uF 50V CER X7R 1206
INPUT CONN MALE 3POS 2.54MM PITCH R/A
L1 IND 33uH 0.42A 0.66OHM
OUTPUT CONN FEMALE 3POS 2.54MM PITCH R/A
P1 CONN-PCB 3POS HEADER WIRE TO BRD WAFER ASSY
STRAIGHT 2MM PITCH (Note 1)
R1 RES 1M 1%THICK FILM 0805
R6, R8, R10, RES THICK FILM 0805 (Note 1)
R11, R12, R13
R14, R15, R16 RES 0 OHM 1% 3/4W 0612
R17, R18 RES THICK FILM 0612 (Note 1)
R2 RES 18.2K 1% THICK FILM 0805
R3 RES 49.9K 1% THICK FILM 0805
R4 RES 1M 1% THICK FILM 0805
R5 RES 187K 1% THICK FILM 0805
R7, R9 RES 0-OHM 1%THICK FILM 0805
U1 IC-ADI HIGH EFFICIENCY SYNCHRONOUS BUCK
VIOC CONN FEMALE 2POS 2.54MM PITCH R/A
DEMO MANUAL SCP-LT8618-IEVALZ
MANUFACTURER/PART NUMBER
ANALOG DEVICES 08_059761a
SUN ELECTRONIC 63CE22BSA
TAIYO YUDEN HMK316B7105KL-T
SAMSUNG CL10B104KC8NNNC
KEMET C0603X473K5RACTU
N/A
SAMSUNG CL31A106MBHNNNE
SAMSUNG CL10B105KP8NNNC
YAGEO CC0603KRX7R9BB103
SAMSUNG CL31B475KBHNNNE
SULLINS PBC03SBAN
WURTH ELEKTRONIK 44031330
SULLINS PPPC031LGBN-RC
MOLEX 53253-0370
YAGEO RC0805JR-071ML
N/A
VISHAY RCL06120000Z0EA
N/A
PANASONIC ERJ-6ENF1822V
PANASONIC ERJ-3EKF4992V
PANASONIC ERJ-6ENF1004V
PANASONIC ERJ-6ENF1873V
VISHAY CRCW08050000Z0EA
ANALOG DEVICES LT8618EDDB#PBF
SULLINS PPPC021LGBN-RC
