Parts List - Linear ANALOG DEVICES LTC7106 Demo Manual

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 1 C2
3 1 C18
4 2 C19, C25
5 1 C22
6 1 C23
7 1 C24
8 1 CIN1
9 6 CIN4, CIN5, CIN6, CIN7, CIN8, CIN9 CAP ., 22µF, X5R, 16V, 20%, 1210
10 8 COUT1, COUT2, COUT3, COUT4,
COUT6, COUT7, COUT11, COUT12
11 3 COUT8, COUT13, COUT14
12 1 Q1
13 7 R2, R3, R7, R11, R12, R16, R54
14 1 R9
15 4 R17, R23, R33, R57
16 1 R18
17 2 R25, R32
18 1 R35
19 1 R40
20 1 R55
21 1 U1
22 1 U2
Additional Demo Board Circuit Components
1 0 C3, C14, C15, C16
2 0 COUT9
3 0 COUT10, COUT15, COUT16
4 0 R8, R15, R19, R21, R22, R38
DEMO MANUAL DC2830A
PART DESCRIPTION
CAP ., 1µF, X5R, 10V, 10%, 0603
CAP ., 100pF, X7R, 25V, 5%, 0603
CAP ., 2200pF, X7R, 25V, 10%, 0603
CAP ., 0.1µF, X5R, 16V, 10%, 0603
CAP ., 4.7µF, X5R, 10V, 10%, 0603
CAP ., 1µF, X5R, 25V, 10%, 0603
CAP ., 22µF, X5R, 6.3V, 20%, 0805
CAP ., 180µF, ALUM. POLY., 25V, 20%, 8x12mm SMD, E12
CAP ., 100µF, X5R, 6.3V, 20%, 1210
CAP ., 470µF, TANT. POSCAP , 4V, 20%, 7343, 12mΩ, TPE,
NO SUBS. ALLOWED
XSTR., MOSFET, N-CH, 40V, TO-252 (DPAK)
RES., AEC-Q200, 10k, 1%, 1/10W, 0603
RES., AEC-Q200, 7.5k, 1%, 1/10W, 0603
RES., 0Ω, 1/10W, 0603
RES., 15k, 1%, 1/10W, 0603
RES., 10Ω, 1%, 1/10W, 0603
RES., AEC-Q200, 2.2Ω, 5%, 1/8W, 0805
RES., 34.8k, 1%, 1/10W, 0603
RES., SENSE, AEC-Q200, 0.01Ω, 1%, 1/2W, 2010
IC, HIGH EFFICIENCY 40A µMODULE, 144-pin BGA
IC, 7-BIT CURRENT DAC WITH DIGITAL, 10-pin DFN
CAP ., OPTION, 0603
CAP ., OPTION, 7343
CAP ., OPTION, 1210
RES., OPTION, 0603
MANUFACTURER/PART NUMBER
MURATA, GRM188R61A105KA61D
AVX, 06033C101JAT2A
AVX, 06033C222KAT2A
AVX, 0603YD104KAT2A
AVX, 0603ZD475KAT2A
AVX, 06033D105KAT2A
MURATA, GRM21BR60J226ME39L
PANASONIC, 25SVPF180M
MURATA, GRM32ER61C226ME20L
MURATA, GRM32ER60J107ME20L
PANASONIC, 4TPE470MCL
VISHAY, SUD50N04-8M8P-4GE3
VISHAY, CRCW060310K0FKEA
VISHAY, CRCW06037K50FKEA
VISHAY, CRCW06030000Z0EA
NIC, NRC06F1502TRF
VISHAY, CRCW060310R0FKEA
VISHAY, CRCW08052R20JNEA
VISHAY, CRCW060334K8FKEA
VISHAY, WSL2010R0100FEA
ANALOG DEVICES, LTM4636EY#PBF
ANALOG DEVICES, LTC7106EDDB#PBF
Rev 0
7
