Overview
This manual provides the basic information needed to install, start-up, and
troubleshoot the PowerFlex 700L Liquid-Cooled AC Drive.
Topic
Who Should Use this Manual?
What Is Not in this Manual
This manual is intended for qualified personnel. You must be able to install,
wire, and operate Adjustable Frequency AC Drive devices. In addition, you
must have an understanding of the parameter settings and functions.
This manual is designed to provide only basic installation and start-up
information. The following information is not included:
PowerFlex 700L Active Converter Power Module Information
Regenerative PowerFlex 700L drives are equipped with a PowerFlex 700L
Active Converter Power Module. For details on active converter I/O wiring,
start-up, programming, and other related information, see the PowerFlex
700L Active Converter Power Module User Manual, publication
PFLEX-UM002.
PowerFlex 700 Vector Control Information (standard)
For PowerFlex 700L drives equipped with Standard Vector Control, see the
PowerFlex 700 Adjustable Frequency AC Drive User Manual - Series B,
publication 20B-UM002, which provides I/O wiring, start-up,
programming, and vector control encoder information.
PowerFlex 700S Phase II Control Information (optional)
For PowerFlex 700L drives equipped with Optional 700S Phase II Control,
see the PowerFlex 700S High Performance AC Drive - Phase II Control
User Manual, publication 20D-UM006, which provides I/O wiring, start-up,
programming, and other related information.
sales@aotewell.com
Page
P-1
P-1
P-2
P-3
P-4
P-5
P-7
PowerFlex 700L Frames 2, 3A, and 3B Liquid-Cooled AC Drives User Manual
Industry Automation
Preface
Publication 20L-UM001E-EN-P
