  • Page 1 PowerFlex 700 Adustable Frequency AC Drive Technical Data...
  • Page 2 Mounting ..........PowerFlex 700 Frames ........
  • Page 3 - DriveTools™ SP. A suite of software tools which provide an intuitive means for programming, troubleshooting and maintaining Allen-Bradley AC & DC drives. • For simplified AC drive start-up and reduced development time, we’ve integrated Allen-Bradley PowerFlex drive configuration with RSLogix5000® software. This single-software approach simplifies parameter and tag programming while still allowing stand-alone drive software tool use on the factory floor.
  • Page 4 (Unconnected Messaging) permits other network devices (e.g. PanelView™) to communicate directly to a drive without routing the commu- nication through the network scanner. Adapter Routing - Plug PC into one drive and talk to all other Allen-Bradley drives on same network, without being routed through network scanner.
  • Page 5 PowerFlex 700 Technical Data Catalog Number Explanation Position 17-18 19-20 Drive ND Rating ND Rating Code Type 400V, 50 Hz Input 480V, 60 Hz Input PowerFlex 700 Code Amps Frame Code Amps Frame 0.37 0.75 Voltage Rating Code Voltage Prechg.
  • Page 6 PowerFlex 700 Technical Data Comm Slot ND Rating Code Operator Interface Code Network Type 600V, 60 Hz Input Code Amps Frame Blank Cover BACnet MS/TP Full Numeric LCD ControlNet (Coax) Prog. Only LCD DeviceNet Remote (Panel Mount), IP66, NEMA/UL EtherNet/IP...
  • Page 7 PowerFlex 700 Technical Data Factory Installed Options Conformal Coat (Position d = M) ‡ Internal Brake IGBT Description Frame Cat. Code Conformal Coat Drive Input Voltage Brake IGBT Frame (Position g) 208…480V AC Standard 0…3 Printed circuit boards are coated with HumiSeal 1B73 0…10...
  • Page 8 PowerFlex 700 Technical Data User Installed Options Human Interface and Wireless Interface Modules No HIM (Blank Plate) LCD Display, Full LCD Display, Wireless Interface 20-HIM-A0 Numeric Keypad Programmer Only Module 20-HIM-A3 20-HIM-A5 20-WIM-N1 Remote (Panel Mount) Remote (Panel Mount) Remote (Panel Mount)
  • Page 9 PowerFlex 700 Technical Data Communication Option Kits Dynamic Brake, Chopper Only Kits Description Cat. No. Description Rating Cat. No. BACnet ® MS/TP RS485 Communication Adapter 20-COMM-B 1336-WA018 ControlNet™ Communication Adapter (Coax) 20-COMM-C 200…240V AC 1336-WA070 ControlNet™ Communication Adapter (Coax) 115A...
  • Page 10 PowerFlex 700 Technical Data Isolation Transformers For installations that have specific types of AC supply configurations or require drive protection due to AC line disturbances, isolation transformers are available. IP32 (NEMA/UL Type 3R) 240V, 60 Hz, Three-Phase, 460V, 60 Hz, Three-Phase, 575V, 60 Hz, Three-Phase, 240V Primary &...
  • Page 11 PowerFlex 700 Technical Data Input/Output Line Reactors For impedance matching, protection from AC line disturbances or motor protection, reactors are available for both the input and output sides of the drive. 240V, 60 Hz, Three-Phase, 3% Impedance Input Line Reactor...
  • Page 12 PowerFlex 700 Technical Data 240V, 60 Hz, Three-Phase, 5% Impedance Input Line Reactor Output Line Reactor IP00 (Open Style) IP11 (NEMA/UL Type 1) IP00 (Open Style) IP11 (NEMA/UL Type 1) Drive Cat. No. Duty Cat. No. Cat. No. Cat. No.
  • Page 13 PowerFlex 700 Technical Data 480V, 60 Hz, Three-Phase, 3% Impedance Input Line Reactor Output Line Reactor IP00 (Open Style) IP11 (NEMA/UL Type 1) IP00 (Open Style) IP11 (NEMA/UL Type 1) Drive Cat. No. Duty Cat. No. Cat. No. Cat. No.
  • Page 14 PowerFlex 700 Technical Data 480V, 60 Hz, Three-Phase, 5% Impedance Input Line Reactor Output Line Reactor IP00 (Open Style) IP11 (NEMA/UL Type 1) IP00 (Open Style) IP11 (NEMA/UL Type 1) Drive Cat. No. Duty Cat. No. Cat. No. Cat. No.
  • Page 15 PowerFlex 700 Technical Data 600V, 60 Hz, Three-Phase, 3% Impedance Input Line Reactor Output Line Reactor IP00 (Open Style) IP11 (NEMA/UL Type 1) IP00 (Open Style) IP11 (NEMA/UL Type 1) Drive Cat. No. Duty Cat. No. Cat. No. Cat. No.
  • Page 16 PowerFlex 700 Technical Data 600V, 60 Hz, Three-Phase, 5% Impedance Input Line Reactor Output Line Reactor IP00 (Open Style) IP11 (NEMA/UL Type 1) IP00 (Open Style) IP11 (NEMA/UL Type 1) Drive Cat. No. Duty Cat. No. Cat. No. Cat. No.
  • Page 17 Same as AC Integral Class 10 Motor Overload Motor Recommendations - See Publication MOTORS-CA001 Single-Phase Input Power The PowerFlex 700 drive is typically used with a three-phase input supply. However, single-phase operation is possible for certain frames as explained below: Frame Condition 0…7...
  • Page 18 An Auxiliary Control Power Supply such as the 20-24V-AUX can be used with 400/480 and 600/690 Volt drives with Vector Control. However, consult the factory before using an auxiliary power supply in these instances. Important: The Auxiliary Control Power Supply Must Not be used with any Standard Control drive or any 200/240V PowerFlex 700 drive, Standard or Vector Control.
  • Page 19 PowerFlex 700 Technical Data Typical Terminal Block Location DANGER Optional Use 75C Wire Only Optional Communications #10-#14 AWG Communications Module Torque to 7 in-lbs Module WIRE STRIP DC– 75C Cu Wire 6 AWG [10MM ] Max. 12 IN. LBS. 1.4 N-M...

  • Page 20: Frames

    PowerFlex 700 Technical Data Typical Terminal Block Locations (continued) DANGER CAUTION HOT SURFACES DANGER DANGER RISK OF SHOCK REPLACE AFTER DANGER SERVICING RISK OF SHOCK REPLACE AFTER SERVICING TB11 25 AMPERES RMS MAXIMUM ALLEN-BRADLEY MADE IN U.S.A. 8 AMPERES RMS...

  • Page 21: Frames

    PowerFlex 700 Technical Data Typical Terminal Block Locations (continued) DANGER DANGER DANGER DANGER RISK OF SHOCK REPLACE AFTER SERVICING 8 AMPERES RMS MAXIMUM DANGER RISK OF SHOCK REPLACE AFTER SERVICING TB11 25 AMPERES RMS MAXIMUM DANGER RISK OF SHOCK REPLACE AFTER...

  • Page 22: Frame

    PowerFlex 700 Technical Data Power Terminals Frame Terminal Block 0 & 1 DC– U (T1) V (T2) W (T3) R (L1) S (L2) T (L3) DC– (T1) (T2) (T3) (L1) (L2) (L3) 3 & 4 * Note: Shaded BR1 & BR2 Terminals will only be present on drives ordered with the Brake Option.

  • Page 23: Frames

    PowerFlex 700 Technical Data Frame Terminal Block AC Input DC Input DC– PE R-L1 S-L2 T-L3 U-T1 V-T2 W-T3 Input Output USE 75° COPPER WIRE ONLY TORQUE LARGE TERMINALS TO 10 N-m (87 LB-IN) U-T1 V-T2 W-T3 OUTPUT 8 & 9 DC–...

  • Page 24: Frames

    PowerFlex 700 Technical Data Frame 8 Fan Connections Drive Rating No. of Type Enclosure (120VAC) Fans Connect at … IP00, NEMA/UL Type Open 500 VA Input IP20, NEMA/UL Type 1 500 VA Requires user supplied 120V AC. See page for TB location and page terminal designations.

  • Page 25: Frame

    PowerFlex 700 Technical Data Fan Transformer Specifications/Fusing Recommended Fuses Frame Rating Primary (Quantity 2) Secondary (Quantity 1) 8 & 9 500 VA 2.8A, 600V AC, KLDR/ATQR Type 6.25A, 250V AC, Time Delay 1000 VA 6A, 600V AC, KLDR/ATQR Type 9A, 250V AC, Time Delay...

  • Page 26: Frame

    A 10k ohm, 2 watt burden resistor must be installed on each digital input when using a triac type device. The resistor is installed between each digital input and neutral /common. These inputs/outputs are dependant on a number of parameters. Refer to the PowerFlex 700 User Manual for details.
  • Page 27 PowerFlex 700 Technical Data Frames 7…10 Vector Control Option (Frames 7…10) No. Signal Description , bipolar, differential, ±10V/4-20mA, 11 Analog In 1 (–) Isolated 320 - bit & sign, 88k ohm input impedance. For 4-20mA, Analog In 1 (+) a jumper must be installed at terminals 17 & 18 (or Analog In 2 (–)
  • Page 28 PowerFlex 700 Technical Data Encoder Terminal Block (Vector Control Option Only) Description (refer to page 73 for encoder specifications) +12V DC Power Internal power source 250 mA. +12V DC Return (Common) Encoder Z (NOT) Pulse, marker or registration input. Encoder Z Encoder B (NOT) Quadrature B input.
  • Page 29 PTC OT cleared < 4V Parameter 259, bit 18 = “Enabled” PTC Short < 0.2V • View Status: Drive Alarm 1: Parameter 211, bit 18 = “True” Refer to the PowerFlex 700 User Manual for important bipolar wiring information. 20B-TD001F-EN-P...
  • Page 30 PowerFlex 700 Technical Data Input/Output Connection Example Required Parameter Changes Analog Output • Configure with Parameter 340 ±10V, 0-20 mA Bipolar • Select Source Value: +10V Unipolar (shown) Parameter 384, [Digital Out1 Sel] Standard Control • Adjust Scaling: 4-20 mA Unipolar Parameters 343/344 + –...
  • Page 31 PowerFlex 700 Technical Data Cable Recommendations Cable Types Acceptable for 200…600 Volt Installations A variety of cable types are acceptable for drive installations. For many installations, unshielded cable is adequate, provided it can be separated from sensitive circuits. As an approximate guide, allow a spacing of 0.3 meters (1 foot) for every 10 meters (32.8 feet) of length.
  • Page 32 PowerFlex 700 Technical Data Power Ratings and Branch Circuit Protection Single-Phase Power Ratings 208/240 Volt Single-Phase AC Input 240V Single-Phase AC Input 208V Single-Phase AC Input Three-Phase Output Three-Phase Output Temp. Drive Catalog Input Drive Catalog Input °C Number Frame...
  • Page 33 PowerFlex 700 Technical Data 600…690 Volt Single-Phase AC Input (continued) 600V Single-Phase AC Input 690V Single-Phase AC Input Three-Phase Output Three-Phase Output Temp. Drive Catalog Input Drive Catalog Input °C Number Frame Rating Amps V AC Amps Number Frame Rating...
  • Page 34 PowerFlex 700 Technical Data (13) 400 Volt AC Input Protection Devices (See page 36 for Notes) Motor Dual Circuit Circuit Input Element Time Non-Time Breaker Protector 140M Motor Protector with Adjustable Drive Rating Freq. Temp. Ratings Output Amps Delay Fuse...
  • Page 35 PowerFlex 700 Technical Data (13) 480 Volt AC Input Protection Devices (See page 36 for Notes) Motor Dual Circuit Circuit Input Element Time Non-Time Breaker Protector 140M Motor Protector with Adjustable Current Drive Rating Freq. Temp. Ratings Output Amps Delay Fuse...
  • Page 36 PowerFlex 700 Technical Data (13) 600 Volt AC Input Protection Devices Motor Dual Circuit Circuit 140M Motor Protector with Adjustable Current Temp. Input Element Time Non-Time Breaker Protector Drive Rating Freq. (11) Ratings Output Amps Delay Fuse Delay Fuse Range...
  • Page 37 PowerFlex 700 Technical Data 325 Volt DC Input Protection Devices (See page 39 for Notes) Temp. DC Input Drive Hp Rating Freq. Ratings Output Amps Catalog Non-Time °C Number Amps Cont. 1 Min. 3 Sec. Fuse Delay Fuse 325 Volt DC Input 20BB2P2 0.33...
  • Page 38 PowerFlex 700 Technical Data Temp. DC Input Non-Time kW Rating Freq. Ratings Output Amps Drive Catalog Delay °C Number Amps kW Cont. 1 Min. 3 Sec. Fuse Fuse (10) 20BP600 1100 170M6615 (10) 1070 1200 170M6616 (10) 20BP730 1095 1200...
  • Page 39 DC Bus. Disconnects: Allen-Bradley Bulletin 1494, 30-400A; 194, 30-400A; or ABB OESA, 600 & 800A; OESL, all sizes. Fuses: Bussmann Type JKS, all sizes; Type 170M, Case Sizes 1, 2 and 3, or Ferraz Shawmut Type HSJ, all sizes. For any other devices, please contact the factory.
  • Page 40 For Further Information on … see Publication … 1321-RWR 1321-TD001 1204-RWR2 1204-5.1 1204-RWC 1204-IN001 1204-TFxx 1204-IN002 PowerFlex 700 (Standard/Vector), 400V Shielded/Unshielded Cable - Meters (Feet) Reactor + Damping Resistor Rating No Solution Reactor Only or 1321-RWR Reactor/RWR Resistor Available Options Frame kHz 1000V 1200V 1488V 1600V 1000V 1200V 1488V 1600V 1000V 1200V 1488V 1600V Cat.
  • Page 41 PowerFlex 700 Technical Data Reactor + Damping Resistor Rating No Solution Reactor Only or 1321-RWR Reactor/RWR Resistor Available Options Frame kHz 1000V 1200V 1488V 1600V 1000V 1200V 1488V 1600V 1000V 1200V 1488V 1600V Cat. No. Ohms Watts 137.2 365.8 365.8 91.4...
  • Page 42 (300) (500) (600) (250) (450) (900) (1200) Requires two parallel cables. Requires three parallel cables. PowerFlex 700 (Standard/Vector), 480V Shielded/Unshielded Cable - Meters (Feet) Reactor + Damping Resistor Rating No Solution Reactor Only or 1321-RWR Reactor/RWR Resistor Available Options Frame kHz 1000V 1200V 1488V 1600V 1000V 1200V 1488V 1600V 1000V 1200V 1488V 1600V Cat.
  • Page 43 PowerFlex 700 Technical Data Reactor + Damping Resistor Rating No Solution Reactor Only or 1321-RWR Reactor/RWR Resistor Available Options Frame kHz 1000V 1200V 1488V 1600V 1000V 1200V 1488V 1600V 1000V 1200V 1488V 1600V Cat. No. Ohms Watts 12.2 137.2 182.9 91.4...
  • Page 44 (40) (100) (300) (400) (100) (200) (500) (700) Requires two parallel cables. Requires three parallel cables. PowerFlex 700 (Standard/Vector), 600V Shielded/Unshielded Cable - Meters (Feet) Rating No Solution Reactor Only 1321-RWR Available Options Frame Hp kHz 1488V 1850V 1488V 1850V...
  • Page 45 365.8 (1200) 1321-RWR160-EP 42.7 (140) 137.2 (450) 45.7 (150) 152.4 (500) 198.1 (650) 365.8 (1200) 1321-RWR160-EP PowerFlex 700 (Standard/Vector), 690V Shielded/Unshielded Cable - Meters (Feet) Rating No Solution Reactor Only Reactor + Damping Resistor Reactor Resistor Available Options Frame kHz 1850V...
  • Page 46 PowerFlex 700 Technical Data Mounting Operating Temperatures PowerFlex 700 drives are designed to operate at 0° to 40° C ambient. To operate the drive in installations between 41° and 50° C, see the information below and refer to pages 33-39 for exceptions.
  • Page 47 PowerFlex 700 Technical Data PowerFlex 700 Frames AC Input 208/240 400V 480V 600V 690V Frame ND Hp HD Hp ND kW HD kW ND Hp HD Hp ND Hp HD Hp ND kW HD kW 0.33 0.37 0.25 0.33 –...
  • Page 48 PowerFlex 700 Technical Data Approximate Dimensions Frames 0…3 (0 Frame Shown) 15.0 (0.59) see below 5.8 (0.23) dia. Weight kg (lbs.) Drive & Drive Packaging 110.0 (4.33) 336.0 (13.23) 200.0 (7.87) 80.0 (3.15) 320.0 (12.60) 5.22 (11.5) 8.16 (18) 135.0 (5.31) 336.0 (13.23)
  • Page 49 PowerFlex 700 Technical Data Frame 5 6.5 (0.26) 15.0 (0.59) 259.1 (10.20) 37.6 (1.48) Detail CAUTION HOT surfaces can cause severe burns Lifting Holes - 4 Places 6.5 (0.26) 12.7 (0.50) Dia. 12.5 (0.49) Dimensions are in millimeters and (inches) Approx.
  • Page 50 PowerFlex 700 Technical Data Frame 6 8.5 (0.33) 18.0 (0.71) 49.6 (1.95) 360.6 (14.20) Detail Lifting Holes 8.5 (0.33) 126.3 4 Places (4.97) 13.5 (0.53) 12.7 (0.50) Dia. Dimensions are in millimeters and (inches) Approx. Weight kg (lbs.) A (Max.) C (Max.)
  • Page 51 PowerFlex 700 Technical Data Bottom View Dimensions Rating Dimensions Rating Dimensions All except 50 Hp, 96.0 (3.78) 105.3 (4.15) 75.0 (2.95) 480V (37 kW, 400V) 94.7 (3.73) 37.3 (1.47) Dia. 22.2 (0.87) Dia. 55.0 (2.17) 2 Places 35.0 (1.38) 28.7 (1.13) Dia.
  • Page 52 PowerFlex 700 Technical Data Rating Dimensions 75 Hp, 104.0 (4.09) 34.9 (1.37) Dia. 2 Places 22.2 (0.87) Dia. 480V 93.2 (3.67) 2 Places (55kW, 400V) 62.7 (2.47) Dia. Normal 2 Places Duty Drive 241.9 (9.52) 229.5 (9.04) 220.0 (8.66) 184.0 (7.24)
  • Page 53 PowerFlex 700 Technical Data Frame 5 NEMA/UL Type 12 Stand-alone – 400…690V Only 609.6 (24.00) 25.4 (1.00) 558.8 (22.00) 105.5 (4.15) Outlet 1574.8 (62.00) DANGER REMOTE SOURCE(S) OF POWER. DISCONNECT ALL SOURCES OF POWER BEFORE OPENING THE DOOR. DANGER 1543.0 ±1.5 ELECTRICAL SHOCK HAZARD FROM ENERGY STORAGE CAPACITORS.
  • Page 54 PowerFlex 700 Technical Data Frame 5 NEMA/UL Type 12 Flange Mount – 400…690V Only 500.0 (19.69) 219.5 (8.64) 196.5 (7.74) 12.7 (0.50) Dia. Lifting Holes - 4 Plcs. 478.0 11.0 (0.43) (18.82) Outlet 127.6 1061.0 (5.02) (41.77) SHLD 1039.0 SHLD (40.91)
  • Page 55 PowerFlex 700 Technical Data Frame 5 Flange Mount Cutout 4.00 (0.157) Dia. Holes (40 Places) in Minimum 14 GA. (1.9) Steel 458.0 10.0 Mounting Surface. Deburr Pilot Holes (18.03) (0.39) and Drive Cutout. 1039.0 (40.91) 1026.5 (40.41) 948.5 (37.34) 870.5 (34.27)
  • Page 56 PowerFlex 700 Technical Data Frame 6 NEMA/UL Type 12 Stand-alone – 400…690V Only 711.3 (28.00) 24.1 (0.90) 663.1 (26.10) 123.6 (4.90) 1828.8 (72.00) 1795.2 (70.70) 1279.5 (50.40) 283.3 (11.20) 16.8 (0.66) 12.7 (0.50) Dia. 13.5 (0.53) Dia. Lifting Holes 4 Places (See Note A) 487.8...
  • Page 57 PowerFlex 700 Technical Data Frame 6 NEMA/UL Type 12 Flange Mount – 400…690V Only 584.0 (23.00) 556.0 (21.90) 201.0 (7.90) 14.0 (0.60) 105.8 (4.17) 1100.0 (43.30) 1078.0 (42.40) 763.3 (30.0) 137.2 127.3 OUTPUT USE 75C COPPER WIRE ONLY, TORQUE 52 IN-LB (6 N-M) (5.40)
  • Page 58 PowerFlex 700 Technical Data Frame 6 Flange Mount Cutout 4.00 (0.157) Dia. Holes (44 Places) in Minimum 14 GA. (1.9) Steel 12.0 532.0 Mounting Surface. Deburr Pilot Holes (0.50) (20.90) and Drive Cutout. 1078.0 (42.40) 1043.0 (41.10) 971.0 (38.20) 899.0 (35.40)
  • Page 59 PowerFlex 700 Technical Data Frame 7 IP20, NEMA/UL Type 1 Dimensions 514.4 (20.25) 477.3 (18.79) 406.9 (16.02) 440.2 (17.33) 1424.2 (56.07) 1447.8 (57.00) PORT NET A NET B 1498.6 (59.00) Lifting Holes 4 Places 406.9 (16.02) 352.8 261.6 (13.89) (10.30) 406.9...
  • Page 60 PowerFlex 700 Technical Data Frames 8 & 9 IP20, NEMA/UL Type 1 Dimensions Depth Drive Catalog No. (Behind Backplane) (Total Depth) 20Bx365, 415, 481 254.0 (10.00) 889.0 (35.00) 20Bx535, 600, 730 381.0 (15.00) 1016.0 (40.00) 549.7 (21.64) 1463.0 (57.60) 2373.9 (93.46)
  • Page 61 PowerFlex 700 Technical Data Frame 10 IP20, NEMA/UL Type 1 Dimensions AC Input Shown, for DC Input Dimensions use the Inverter (Left) Bay 889.0 (35.00) 2373.9 (93.46) 757.7 503.7 (29.83) (19.83) 1267.7 (49.91) Dimensions are in millimeters and (inches) Approx. Weight kg (lbs.)
  • Page 62 PowerFlex 700 Technical Data Frame 7 IP00, NEMA/UL Type Open Dimensions 514.4 (20.25) 477.3 (18.79) 406.9 (16.02) 440.2 (17.33) DANGER 1424.2 (56.07) 1447.8 CAUTION (57.00) HOT SURFACES 1498.6 (59.00) DANGER RISK OF SHOCK REPLACE AFTER SERVICING TB11 25 AMPERES RMS...
  • Page 63 PowerFlex 700 Technical Data Frames 8 & 9 IP00, NEMA/UL Type Open Dimensions 757.7 (29.83) 145.3 (5.72) Table 614.4 (24.19) 256.8 (10.11) 549.7 104.4 (4.11) 71.4 (2.81) (21.64) 1524.0 (60.00) 1463.0 (57.60) DANGER DANGER 2275.8 RISK OF SHOCK REPLACE AFTER SERVICING (89.60)
  • Page 64 PowerFlex 700 Technical Data Frames 8 & 9 Roll-In IP00, NEMA/UL Type Open Dimensions 1612.4 (63.48) DANGER DANGER RISK OF SHOCK REPLACE AFTER SERVICING DANGER 8 AMPERES RMS MAXIMUM DANGER RISK OF SHOCK REPLACE AFTER SERVICING TB11 25 AMPERES RMS MAXIMUM 45.2...
  • Page 65 PowerFlex 700 Technical Data Frames 8 & 9 Roll-In Mounting Considerations Typical Bracket (May require additional anchoring for shipping) Suggested Anchoring Point Typical Fan Location (M10 Hardware Required) (2 Places - 1 Each Door) Alternate Fan Locations Typical Rail Detail 107.4...
  • Page 66 PowerFlex 700 Technical Data Frames 8 & 9 DC Link Choke Dimensions 19.1 (0.75) 16.0 x 9.7 (0.63 x 0.38) 4 Places 217.9 (8.58) 179.8 228.6 Frame 8 (7.08) (9.00) Max. 370.8 (14.60) 396.2 (15.60) 279.4 (11.00) 203.2 (8.00) 4.7 (0.19) 54.1...
  • Page 67 PowerFlex 700 Technical Data Frame 10 IP00, NEMA/UL Type Open AC Input Shown, for DC Input Dimensions use the Inverter (Left) Bay 543.1 (21.38) 591.3 (23.28) 445.8 (17.55) 353.8 (13.93) DANGER DANGER DANGER DANGER RISK OF SHOCK REPLACE AFTER SERVICING...
  • Page 68 PowerFlex 700 Technical Data Frame 7 Flange Mount Cutout 508.0 (20.00) 489.0 (19.25) 127.0 54.1 (5.00) (0.23) (2.13) 477.3 (18.79) Cutout 1084.1 (42.68) Shading indicates approximate size of drive inside enclosure. 1422.4 (56.00) 1095.8 (43.14) 26 Required 4.3 (0.171) Dia. for 10-32 x 9.7 (0.38) Self-Tap 4.0 (0.159) for 10-32 x 9.7 (0.38) Threaded...
  • Page 69 PowerFlex 700 Technical Data Frame 8 & 9 Flange Mount Cutout 583.7 (22.98) 553.5 (21.79) 15.0 (0.59) 152.4 203.2 152.4 22.6 (0.89) (6.00) (8.00) (6.00) 5.6 (0.22) 52.1 (2.05) 20 Places 279.4 (11.00) 279.4 (11.00) 1471.9 (57.95) 279.4 1493.5 (11.00) (58.80)
  • Page 70 PowerFlex 700 Technical Data Frame 10 Flange Mount Cutout – DC Input 508.0 (20.00) 22.9 22.9 32.3 (1.27) 355.6 (14.00) (0.90) (0.90) 39.9 (1.57) 152.4 37.8 38.1 152.4 152.4 7.6 (0.30) (6.00) (1.49) (1.50) (6.00) (6.00) 52.1 (2.05) 553.5 (21.79) 381.0 (15.00)
  • Page 71 PowerFlex 700 Packaged Drives Product Description PowerFlex 700 Packaged Drives are ideal for global Original Equipment Manufacturers (OEM) and end users with special installation needs. This program simplifies installation and start-up by allowing users to order drive packages that combine operator interface, control, communications and power options in pre-configured assemblies. Designed to meet customer demands for space savings, application flexibility and reliability, Packaged PowerFlex 700 AC drives offer a number of commonly requested pre-engineered options, as well as more complex custom-engineered packages.
  • Page 72 PowerFlex 700 Technical Data Specifications Control and Performance Frames 0…4 Category 5…6 7…10 Specification 230…480V 600V Agency Listings, Listed to UL508C and CAN/CSA-C22.2 No. 14-05. Certification or Packaged drives may be listed to UL508A Tests EC-Type-Examination Certificate TUV 05 ATEX 7153 for directive 94/9/EC: Safe turn off of certified ATEX motors used in Group II Category (2) GD potentially explosive atmospheres.
  • Page 73 PowerFlex 700 Technical Data Category Specification Environment Sound: Frame Fan Speed Sound Level (continued) 30 CFM 58 dB 30 CFM 59 dB 50 CFM 57 dB 120 CFM 61 dB 190 CFM 59 dB 200 CFM 71 dB Note: Sound pressure level is measured at 2 meters.
  • Page 74 PowerFlex 700 Technical Data Watts Loss (Rated Load, Speed & PWM) IP20, NEMA/UL Type 1 – Frames 0…6 IP54, NEMA/UL Type 12 – Frames 0…6 Voltage ND Hp/kW External Watts Internal Watts Total Watts Loss Voltage ND Hp External Watts...
  • Page 75 PowerFlex 700 Technical Data Voltage Tolerance Drive Rating Nominal Line Voltage Nominal Motor Voltage Drive Full Power Range Drive Operating Range 200…240 200* 200…264 180…264 208…264 230…264 380…480 380* 380…528 342…528 400…528 460…528 500…600 575* 575…660 432…660 (Frames 0…4 Only) 500…690...
  • Page 76 PowerFlex 700 Technical Data Ambient Temperature/Load 240V AC Power Rating Power Rating Derating Derating Cont. Cont. ND Hp HD Hp Amps 2 kHz 4 kHz 6 kHz 8 kHz 10 kHz ND Hp HD Hp Amps 2 kHz 4 kHz...
  • Page 77 PowerFlex 700 Technical Data 400V AC Power Rating Power Rating Derating Derating Cont. Cont. ND kW HD kW Amps 2 kHz 4 kHz 6 kHz 8 kHz 10 kHz ND kW HD kW Amps 2 kHz 4 kHz 6 kHz...
  • Page 78 PowerFlex 700 Technical Data 480V AC Power Rating Power Rating Derating Derating Cont. Cont. ND Hp HD Hp Amps ND Hp HD Hp Amps 2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 2 kHz 4 kHz 6 kHz...
  • Page 79 PowerFlex 700 Technical Data Power Rating Power Rating Derating Derating Cont. Cont. ND Hp HD Hp Amps ND Hp HD Hp Amps 2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 2 kHz 4 kHz 6 kHz 8 kHz...
  • Page 80 PowerFlex 700 Technical Data 600V AC Power Rating Power Rating Derating Derating Cont. Cont. ND Hp HD Hp Amps ND Hp HD Hp Amps 2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 2 kHz 4 kHz 6 kHz...
  • Page 81 PowerFlex 700 Technical Data Power Rating Power Rating Derating Derating Cont. Cont. ND Hp HD Hp Amps ND Hp HD Hp Amps 2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 2 kHz 4 kHz 6 kHz 8 kHz...
  • Page 82 PowerFlex, Zero Stacking, Force Technology, DriveExplorer, DriveTools SP, DPI and PanelView are trademarks of Rockwell Automation. Trademarks not belonging to Rockwell Automation are property of their respective companies. www.rockwellautomation.com Power, Control and Information Solutions Headquarters Americas: Rockwell Automation, 1201 South Second Street, Milwaukee, WI 53204 USA, Tel: (1) 414.382.2000, Fax: (1) 414.382.4444 Europe/Middle East/Africa: Rockwell Automation, Vorstlaan/Boulevard du Souverain 36, 1170 Brussels, Belgium, Tel: (32) 2 663 0600, Fax: (32) 2 663 0640 Asia Pacific: Rockwell Automation, Level 14, Core F, Cyberport 3, 100 Cyberport Road, Hong Kong, Tel: (852) 2887 4788, Fax: (852) 2508 1846 20B-TD001F-EN-P –...
