Danfoss ECL Comfort 210 Operating Manual page 87

Operating Guide ECL Comfort 210 / 310, application A231 / A331
MENU > Settings > Application
Min. act. time (min. activation time gear motor)
The min. pulse period of 20 ms (milliseconds ) for activation of the gear
motor.
See Appendix "Parameter ID overview"
VI.LG.P2.02
Example: Override to Frost protection mode
# 1 # = Override switch (not activated / activated)
# 2 # = Function mode (Schedule / Frost pr.)
# 3 # = Time
Example: Override to Constant temperature mode
# 1 # = Override switch (not activated / activated)
# 2 # = Function mode (Schedule / Const. T)
# 3 # = Time
The "Const. T" value can be influenced by:
• temp. max.
• temp. min.
• room temp. limit
• return temp. limit
• flow / power limit
Setting example
2
1x189
10
50
The setting should be kept as high as acceptable to increase the
lifetime of the actuator (gear motor).
Value x 20 ms
40 ms
200 ms
1000 ms
© Danfoss | 2017.11 | 87
