Operating Guide ECL Comfort 210 / 310, application A231 / A331
MENU > Settings > Flow / power limit
High limit Y2 (flow / power limitation, high limit, Y-axis)
Set the flow / power limitation referring to the outdoor temperature set
in 'Low T out X2' .
See Appendix "Parameter ID overview"
The corresponding X coordinate is set in 'Low T out X2' .
MENU > Settings > Flow / power limit
Low limit Y1 (flow / power limitation, low limit, Y-axis)
Set the flow / power limitation referring to the outdoor temperature set in
'High T out X1' .
See Appendix "Parameter ID overview"
The corresponding X coordinate is set in 'High T out X1' .
MENU > Settings > Flow / power limit
Low T out X2 (flow / power limitation, low limit, X-axis)
Set the outdoor temperature value for the high flow / power limitation.
See Appendix "Parameter ID overview"
The corresponding Y coordinate is set in 'High limit Y2' .
MENU > Settings > Flow / power limit
High T out X1 (flow / power limitation, high limit, X-axis)
Set the outdoor temperature value for the low flow / power limitation.
See Appendix "Parameter ID overview"
The corresponding Y coordinate is set in 'Low limit Y1' .
64 | © Danfoss | 2017.11
1x116
1x117
The limitation function can overrule the set 'Temp. min' of the desired
flow temperature.
1x118
1x119
