C H A P T
4
E R
Cabling interfaces
and ports
This chapter shows you the cabling requirements for the DataSMART T3/E3 IDSU net-
work interface, data port, and control port. It also shows you how to cable the unit for
daisy-chaining.
After completing these cabling procedures, you will be ready to configure the port soft-
ware as described in
The port types are covered in the following order:
Network interface
HSSI data port
V.35/EIA-530 user-programmable data port
Control ports
Daisy-chaining
Pinouts for the various pin connectors are provided in
Chapter 5.
(page 29)
(page 29)
(page 31)
(page 33)
(page 30)
Appendix A.
27
