Power up the chassis

Connecting to an AC
power source
Plug one of these cables into the AC power connector
Part number Description of cable
90000 US power cord
90001 EC power cord
90002 UK power cord
90003 Italy power cord
90004 Australia power cord
22 Chapter 3: Initial installation and power up
You power up the chassis by connecting its power cord to an appropriate power source.
CAUTION!
The power supply should be the first electrical connection connected when
installing the IDSU, and the last electrical connection disconnected when
removing the IDSU.
Connect the installed AC power supply to a grounded power receptacle of the appropriate
voltage. The voltage requirements are specified on the rear panel of the power supply.
Plug the power cord into the DataSMART T3/E3 IDSU power input connector first, then
into the power receptacle.
Secure the power cord to the back panel of the IDSU with a plastic cable tie to prevent the
cord from being unplugged inadvertently.
Kentrox has several options for AC power cords to support applications in
different countries.
