Summary of Contents for Kentrox DataSMART T3/E3 IDSU
- Page 1 ® DataSMART T3/E3 IDSU Installation Guide Document #5000163...
- Page 2 You may verify product specifications by contacting our office. In no event shall Kentrox be liable for any damages resulting from loss of data, loss of use, or loss of profits. Kentrox further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages.
-
Page 3: Table Of Contents
Contents Preface..............5 Chapter 1 Getting started Select an appropriate... - Page 4 Chapter 4 Cabling interfaces and ports Network interface............28 HSSI data port.
-
Page 5: Preface
Who should read this This manual is intended to be used by trained and qualified service personnel. It explains how to install the DataSMART T3/E3 IDSU and its components. It con- manual? tains everything the installer needs to know to power up the IDSU and confirm that it is functioning correctly. - Page 6 This manual contains the following information: “Preface” (this section) explains the purpose and organization of this manual and explains how to contact Kentrox Customer Support if you should run into difficulties. “Getting started” describes site and environmental requirements and shows how to unpack and inspect the shipment.
- Page 7 Who to call for If you need assistance with this product or have questions not answered by this manual, please visit our Support page on the Kentrox Web site. You are also wel- assistance come to call or send email to our Technical Assistance Center. Please have your product's software revision and hardware serial numbers available to give to the Support representative.
- Page 8 WARNING! This equipment uses double pole/neutral fusing. For continued protection against risk of fire, replace the fuse only with a fuse of the same type and rating. Precautionary This document uses the following symbol to denote safety precautions you should adhere to while performing the installation procedures.
-
Page 9: Chapter 1 Getting Started
Getting started This chapter tells you how to prepare for installation of the DataSMART T3/E3 IDSU. Topics include: Selecting an appropriate installation site Unpacking the shipping cartons and inspecting their contents to ensure there is no shipment damage Reviewing the front and back panels, and their controls, connectors, and indicators... -
Page 10: Select An Appropriate Site
Power The DataSMART T3/E3 IDSU operates from AC or DC power, depending on the type of power supply you ordered with the unit. Make sure that your installation site provides an appropriate power source for your power supply. The power requirements are listed below. -
Page 11: Esd Precautions
(102 mm) is required at the rear of the unit for cable installation. CAUTION! Damage to the DataSMART T3/E3 IDSU may occur if appropriate clearances around the enclosure are not provided for cooling. Figure 1—DataSMART T3/E3 IDSU dimensions and clearance requirements 1 in. -
Page 12: Unpack Your Shipment
Unpack your shipment Once you’ve selected the installation site, unpack the DataSMART T3/E3 IDSU ship- ment. Inspect the shipment carefully to ensure that there is no shipment damage. Start by inspecting the shipping cartons for shipment damage. If there is evidence of... -
Page 13: Location Of Controls And Indicators
Location of controls and indicators Take a moment to become familiar with the DataSMART T3/E3 IDSU controls and indi- cators. You will need to refer to these throughout the rest of this install procedure. Figure 2—Front panel Network Power LED... -
Page 15: Chapter 2 Preparing The Hardware For Installation
Preparing the hardware for installation To initially access the DataSMART T3/E3 IDSU user interface, you will need to connect a control device to the IDSU control port. Two control ports are provided, a DCE port for connecting a terminal (or a PC running terminal emulation software), and a DTE port for connecting a terminal or PC via a modem. -
Page 16: Resetting The Idsu Terminal Parameters
Resetting the IDSU terminal parameters You can change the DataSMART T3/E3 IDSU default settings for baud rate, parity, and data and stop bits by using the DIP switch located on the IDSU circuit board. To access this board, you need to remove the IDSU side panel as shown in... -
Page 17: Reset The Dip Switches
Reset the DIP When the internal DIP switch is exposed, set them to the required values. switches down Parity setting Baud setting none (default) down down 9600 (default) down down none down 4800 down up down 2400 down even 1200 Data bits Stop bits 8 data bits per character... -
Page 18: Enabling/Disabling Alarms Via The Internal Dip Switch
Enabling/disabling alarms via the internal DIP switch In addition to the terminal settings, the IDSU internal DIP switch allows you to enable or disable alarm messages out the control port. Switch 7 enables or disables alarm messages. Switch 8 specifies whether, if alarms are enabled, they are output via the DCE control port or via the DTE control port. -
Page 19: Chapter 3 Initial Installation And Power Up
Initial installation and power up This chapter tells you how to install and power up the DataSMART T3/E3 IDSU unit. It assumes that all internal DIP switches have been set, and that the unit’s side panel is in place. Topics included here:... -
Page 20: Install The Chassis
4 in. (102 mm) clearance at rear Mounting the IDSU The DataSMART T3/E3 IDSU can stand alone on a flat surface, as long as you adhere to the clearance requirements specified above. Rubber feet are provided but are not required on a desktop for clearance. -
Page 21: Mounting The Idsu In A Rack
Mounting the IDSU in Each unit is supplied with two metal ears for rack mounting. The figure below shows two options for mounting: a 19-inch rack and a 23-inch rack. a rack Note that the ears are not identical. The ear intended for the right side of the unit (as viewed from the front) is marked with a part number beginning with the letter “R”. -
Page 22: Power Up The Chassis
The voltage requirements are specified on the rear panel of the power supply. power source Plug the power cord into the DataSMART T3/E3 IDSU power input connector first, then into the power receptacle. Secure the power cord to the back panel of the IDSU with a plastic cable tie to prevent the cord from being unplugged inadvertently. -
Page 23: Source
Connecting to a DC Connect the installed DC power supply to a power source capable of supplying the appropriate voltage and current. The requirements are specified on the rear panel of the power source supply. Wire the power supply as described below. Wiring the DC power connector Turn off the DC power source. -
Page 24: Using The Alarm
Using the alarm relay The DataSMART T3/E3 IDSU provides an external alarm relay switch that you can use to trigger an external alarm device. This switch provides normally-open and normally-closed positions. Wire the alarm relay as follows: Prepare three 14 to 22 AWG (1.63 to 0.64 mm) wires to terminate in the alarm relay plug. -
Page 25: Self-Test Diagnostics
Telnet, self-test will break your remote connection. Successful power up The self-test verifies the functions of DataSMART T3/E3 IDSU hardware circuitry. The results of self-test are indicated by the POWER/FAIL LED on the front of the unit. This LED glows red for approximately 6 seconds until the self-test completes. -
Page 27: Chapter 4 Cabling Interfaces And Ports
Cabling interfaces and ports This chapter shows you the cabling requirements for the DataSMART T3/E3 IDSU net- work interface, data port, and control port. It also shows you how to cable the unit for daisy-chaining. After completing these cabling procedures, you will be ready to configure the port soft-... -
Page 28: Network Interface
Network interface The T3/E3 network interface receives and transmits data over two 75-ohm coaxial cables with BNC connectors. These cables are shipped with protective caps on the BNC connec- tors. Leave the caps in place until you are ready to connect the cables. Network interface Cables and adapters Part number... -
Page 29: Hssi Data Port
HSSI data port You connect to the HSSI data port via a 50-pin connector. HSSI data port Cables and adapters Part number Description of cable 960005011 HSSI plug (male) to HSSI plug (male), 5, 10 or 15 feet Maximum lengths 15 meters (50 ft.) per EIA-612 Connector pinout Table 4 on page... -
Page 30: V.35/Eia-530 User-Programmable Data Port
V.35/EIA-530 user-programmable data port The user-programmable V.35/EIA-530 data port connects to data terminal equipment (DTE) through a 25-pin socket (female) connector. When set to EIA-530, the port also supports RS449 and X.21 interfaces with appropriate cables and adapters. V.35/EIA-530 data port V.35 Cables and adapters Part number Description of cable... -
Page 31: Connecting The Rear-Panel Control Ports
DTE port. The DataSMART T3/E3 IDSU control ports are set to the following defaults: 9600 baud, 8 data-bits-per-character, 1-stop bit-per-character, and no parity. You must either set your terminal to match the port settings or change the port settings to match your terminal settings. - Page 32 Connecting control ports to a modem Connect a modem to the DTE port after configuring the modem with the AT commands in the list below. It is essential to configure the modem before connecting it to the DTE port because many modems cannot be configured afterwards. This configuration sets auto- answering, flow control, and some other parameters essential to successful communication.
-
Page 33: Configuring Units Via A Daisy-Chain
Configuring units via a daisy-chain Daisy-chaining allows you a single point of control for many units. The manner in which you cable the units together depends on whether you are using a DCE or DTE control port. Using the DCE Make sure the physical communications parameters (baud rate, data bits, stop bits, etc.) for all ports are set up identically. - Page 34 Procedure 2 Set the baud rate, parity, data and stop bits correctly on the next IDSU, as specified page Connect the power cord and power on the unit, as specified on page Connect the next IDSU DCE port to the DTE port of the IDSU you just set up. Press the Enter key.
-
Page 35: Using The Dte Control Port
Using the DTE Cable the daisy-chained units as shown in Figure 9 when you plan to access the first unit in the chain via a modem connected to unit’s rear-panel DTE control port. control port Figure 9—Cabling daisy-chained units through a modem DCE DTE DCE DTE DCE DTE... - Page 36 Procedure 2 Set the baud rate, parity, data and stop bits correctly on the next IDSU, as specified page Connect the power cord and power on the unit, as specified on page Press the Enter key. This logs you into the next unit and brings up its Main menu. Enter the DE command to disable echo.
-
Page 37: Chapter 5 Initial Configuration
DataSMART T3/E3 IDSU User’s Guide for additional configuration or performance monitoring information. Topics covered include: Network configuration (page Data port configuration (page Verifying the configuration (page Procedures for setting up SLIP Telnet or IP access to the DataSMART T3/E3 IDSU are provided in Chapter 7 of your user’s guide. -
Page 38: Logging In
Note that the colon delimit- ers are required. Logging out You should always log out of the DataSMART T3/E3 IDSU when you are done, however, the Auto Logout feature logs you out automatically after 15 minutes with no activity. To log out, enter <Ctrl-D>. -
Page 39: Network Configuration
Network configuration Set up the system clock Specify the system reference clock by entering one of the following commands: CLK:L for looping the network receive timing CLK:I for using the IDSU internal oscillator Always use the loop timing option if the network receive signal supplies timing. There should only be one timing source in the T3 or E3 circuit. -
Page 40: Data Port Configuration
Data port configuration Specify the port physical interface Enter the type of data port connection you are using: HSSI EIA530 (also supports EIA-449, RS449) The default is HSSI. Set the port clock rate Use the following command to set the data port clock rate. This rate should be com- patible with your DTE. -
Page 41: Verifying The Configuration
Verifying the configuration The front-panel LEDs alert you if the DataSMART T3/E3 IDSU is experiencing abnormal conditions. The following figures show the LEDs during normal and abnormal conditions. Figure 10—LEDs when conditions are normal Yellow: internal loopback Yellow: remote loopback set code is set. - Page 42 Table 2—LED indicators and their meanings Indicator Condition POWER/FAIL Green Power is on, self-test successful. Power is on, self-test failed. No power is being received. LOOP / FEL Yellow Internal loopback is set. Yellow, flashing Remote loopback is set and verified. SEND Yellow Remote loopback set code is...
- Page 43 Table 2—LED indicators and their meanings (continued) Indicator Condition DATA Green Valid data is being received at the network interface. Code violation detected at the network interface. Loss of signal detected at the network interface. Out-of-frame condition detected at the network interface. Alarm indication signal (AIS) is being received at the network interface.
-
Page 45: Appendix A Connector Pinouts
A P P E N D I X Connector pinouts This appendix contains the pinouts for the following connectors: Control port pinout (page HSSI data port pinout (page EIA-530 pinout (page V.35 pinout (page... - Page 46 Table 3—Control port pin assignments CCITT Signal name Ring Indicator (RI) Input Output Rec Sign Det (DCD) Input Output 108.2 DTE Ready (DTR) Output Input Signal GND — — Received Data Input Output Transmit Data Output Input Clear To Send (CTS) Input Output Request To Send (RTS)
- Page 47 Table 5—DB25D connector pin assignments for EIA-530 Designator Circuit name Source CCITT/EIA — Shield — (a) 103/BA BA (A), Transmitted Data (a) 104/BB BB (A), Received Data A (a) 105/CA CA (A), Request To Send A (RTS) (a) 106/CB CB (A), Clear To Send A (CTS) (a) 107/CC CC (A), DCE Ready (DSR) 102/AB...
- Page 48 Table 6—DB25D connector pin assignments for V.35 CCITT Circuit name Source — Protective GND — (a) 103 Tx Data A (a) 104 Rx Data A Signal GND — Rec Line Sig Det (DCD) (b) 115 Rx Timing B — Not used —...
-
Page 49: Appendix B Using The Front-Panel Thumbwheel
A P P E N D I X Using the front-panel thumbwheel The front-panel thumbwheel switch allows you to set local and remote loopbacks. It also lets you reset the unit to factory defaults, overriding any configuration edits made previously. DataSMART ... - Page 50 Set the Push... The following action results... thumbwheel to... 4 (LLB) ACTV Sets a line loopback at the near-end cmmd equivalent=SLL 5 (PLB) ACTV Sets a payload loopback at the near-end cmmd equivalent=SPL 6 (LOC) ACTV Sets a local loopback at the near-end cmmd equivalent=SLO 7 (DTLB) ACTV...
-
Page 51: Index
Index connecting to an AC power source, 22 connectors, 30 control ports pinout, 47 AC power source, connecting, 22 cables and adapters, 31 signal requirements, 30 alarm dial-out, 18 connecting, 31 electrostatic discharge (ESD), alarm messages connecting to a modem, 32 precautions, 11 Alarm History report, 18 DCE, 15... - Page 52 removing side panel, 16 replacing side panel, 17 M13 framing, 39 X.21 interface, 30 RS449 interface, 30 MIB source files, accessing, 6 modem, configuring, 32 mounting desktop, 20 safety precautions, 7 rack, 21 self-test diagnostics, 25 side panel removing, 16 replacing, 17 network interface signal requirements...
