54 C 3: S
HAPTER ETTING
Web Management
Over the Network
Setting Up SNMP
Management
U M
P FOR ANAGEMENT
Variable Width Font - Size 10.0
■
Fixed Width Font - Size 12.0
■
This ensures that the text spacing is correct. Finally in the Advanced
category ensure that Enable Java Script and Enable style sheets are
checked.
To manage a Switch using the web interface over an IP network:
1 Check that you have the IP protocol correctly installed on your
management workstation. You can check this by trying to browse the
World Wide Web. If you can browse, the IP protocol is installed.
2 Check you can communicate with the Switch by entering a ping
command at the DOS prompt in the following format:
c:\ ping xxx.xxx.xxx.xxx
(where xxx.xxx.xxx.xxx is the IP address of the Switch)
If you get an error message, check that your IP information has been
entered correctly and the Switch is powered up.
3 Open your web browser and enter the IP address of the Switch that you
wish to manage in the URL locator, for example, in the following format:
http://xxx.xxx.xxx.xxx
4 At the login and password prompts, enter
press Return at the password prompt (or the password of your choice if
you have already modified the default passwords).
5 Click on the Device View button to display the web management options.
Any network management application running the Simple Network
Management Protocol (SNMP) can manage a Switch if:
The correct Management Information Bases (MIBs) are installed on the
■
management workstation.
The management workstation is connected to the Switch using a port
■
in VLAN 1 (the Default VLAN). By default, all ports on the Switch are in
VLAN 1.
You can use the 3Com Network Supervisor application that is provided on
the CD-ROM that accompanies your Switch to provide SNMP
management for your Switch. If you use 3Com Network Supervisor it
as your user name and
admin
