Clack Valve WS1 CD Matrix Operation And Instruction Manual page 59

Volume Regeneration
Capacity Time Option
DELAYED
AUTO
REGEN
DELAYED
AUTO
REGEN
Any DELAYED
number REGEN
DELAYED
OFF
REGEN
Any DELAYED
number REGEN
AUTO IMMEDIATE
Any
IMMEDIATE
number
DELAY +
AUTO
IMMEDIATE
DELAY +
AUTO
IMMEDIATE
Any DELAY +
number IMMEDIATE
4
Reserve capacity estimate is based on history of water usage
Setting Options Table
Filters should only use shaded options.
Day
Override
Reserve capacity automatically estimated.
OFF Regeneration occurs when volume capacity falls below the reserve
capacity at the next Regen Set Time
Reserve capacity automatically estimated.
Any Regeneration occurs at the next Regen Set Time when volume capacity
number falls below the reserve capacity or the specifi ed number of days between
regenerations is reached.
Reserve capacity not automatically estimated.
OFF Regeneration occurs at the next Regen Set Time when volume
capacity reaches 0.
Reserve capacity not automatically estimated.
Any
Regeneration occurs at the next Regen Set Time when the specifi ed
number
number of days between regenerations is reached.
Reserve capacity not automatically estimated.
Regeneration occurs at the next Regen Set Time when volume
Any
capacity reaches 0 or the specifi ed number of days between
number
regenerations is reached.
Reserve capacity not automatically estimated.
Regeneration occurs immediately when volume capacity reaches 0.
OFF Time of regeneration will not be allowed to be set because regeneration
will always occur when volume capacity reaches 0.
Reserve capacity not automatically estimated.
Regeneration occurs immediately when volume capacity reaches 0.
OFF
Time of regeneration will not be allowed to be set because regeneration
will always occur when volume capacity reaches 0.
Reserve capacity automatically estimated.
Regeneration occurs when volume capacity falls below the reserve
OFF
capacity at the next Regen Set Time or regeneration occurs after 10
minutes of no water usage when volume capacity reaches 0.
Reserve capacity automatically estimated.
Regeneration occurs at the next Regen Set Time when volume capacity
Any
falls below the reserve capacity or the specifi ed number of days between
number
regenerations is reached or regeneration occurs after 10 minutes of no
water usage when volume capacity reaches 0.
Reserve capacity not automatically estimated.
Any Regeneration occurs at the next Regen Set Time when the specifi ed
number number of days between regenerations is reached or regeneration occurs
after 10 minutes of no water usage when volume capacity reaches 0.
4
Result
Page 59
