Clack Valve WS1 CD Matrix Operation And Instruction Manual page 32

WS1CH Drive Cap Assembly, Downfl ow Piston, Upfl ow Piston, Regenerant Piston and Spacer Stack Assembly
Drawing No. Order No.
1 V3005
2 V3004
3 V3178
4a V3011*
4b V3011-01*
5 V3174
6 V3135
7 V3180
8 V3105
V3001
V3001-02
Not Shown
V3001UP
V3001-02UP WS1 Mixing Valve Body Upfl ow ASY
*V3011 is labeled with DN and V3011-01 is labeled with UP.
Note: The regenerant piston is not used in backwash only applications.
4b
2
Page 32
Description
WS1 Spacer Stack Assembly
Drive Cap ASY
WS1 Drive Back Plate
WS1 Piston Downfl ow ASY
WS1 Piston Upfl ow ASY
WS1 Regenerant Piston
O-ring 228
O-ring 337
O-ring 215 (Distributor Tube)
WS1 Body ASY Downfl ow
WS1 Mixing Valve Body ASY
WS1 Body ASY Upfl ow
4a
6
Quantity
1
1
1
1
1
1
1
1
1
3
1
5
Black Plug
7
8
