Using a cable ending with two standard XLR connectors connect DB9009-RX analog signal

outputs to the analog audio inputs of your equipment.

Using a cable ending with a standard XLR connectors connect DB9009-RX AES/EBU output

to the digital audio input of your equipment.

For normal operation it is necessary DB9009-RX to be connected to a local network or Internet

by cable with RJ-45 connector.

Using standart DB-9 cable connect DB9009-RX to any RS-232 compatible equipment.

The current audio source can be selected/forced using this GPI port.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com

Basic Setup

- 20 -

Tel: +359 56 820027, Fax: +359 56 836700
