Using a cable ending with two standard XLR jacks connect the analog signal source to the

analog audio inputs of DB9009-TX.

WARNING:

Do not exceed maximum input level. This may permanently damage the device.

Using a cable ending with a standard XLR jacks connect the S/PDIF signal source to the digital

audio input of DB9009-TX.

NOTE:

As only one input can be managed by the encoder at certain point of time, please select

the preferred signal source input – either analog or digital one. Selecting the preferred input can be

performed under CONFIGURATION menu

For normal operation it is necessary the encoder to be connected to a local network or Internet

by cable with RJ-45 connector.

Using standart DB-9 cable connect DB9009-TX to any RS-232 compatible equipment.

The current audio source can be selected/forced using this GPI port.
