Chapter III. Unified Wire Manager (UM)
Network troubleshooting
This module allows detecting and troubleshooting various network connectivity issues. The Ping
utility helps to contact a system by specifying IP address, Number of ICMP packets to send and
packet timeout. The result of the ping can be viewed by clicking on the Ping Result button.
Using TraceRoute one can determine the route taken by packets across an IP network.
Use the GetConnections utility to view currently active TCP/UDP connections. Offload status
for each connection is also displayed if protocol offload hardware is available. This is useful for
troubleshooting any connectivity issues for clients to various services.
Figure 8.6.3 (h) - Ping Utility
