- Page 1 HD09 Series Smart Inverter User Manual Single-phase 220 - 240V, 0.25 - 2.2kW Three-phase 380 - 460V, 0.4 - 5.5kW V1.1 2017.07...
- Page 2 FOREWORD Thank you for purchasing HD09 series smart inverter manufactured by Shenzhen Hpmont Technology Co., Ltd. This User Manual describes how to use HD09 series inverters and their installation wiring, parameter setting, troubleshooting and daily maintenance etc. Before using the product, please read through this User Manual carefully. In addition, please do not use this product until you have fully understood safety precautions.
- Page 3 Version and Revision Records Version information: At the bottom right corner of the front cover. Time: 2017/07 Version: V1.1 Revised chapter Revised contents • Chapter 4 AI termials can be selected as DI input, see clause 4.2 • Chapter 5 Modify input and output routh, see clause 5.1.1 •...
-
Page 4: Table Of Contents
CONTENTS Chapter 1 Safety Information ..........................1 Chapter 2 Product Information ..........................3 2.1 Nameplate ................................. 3 2.2 Rated Value ................................4 Chapter 3 Machenical Installation .......................... 5 3.1 Dimension and Weight ............................5 ... -
Page 6: Chapter 1 Safety Information
Shenzhen Hpmont Technology Co., Ltd. Chapter 1 Safety Information Chapter 1 Safety Information Safety Definition Pay attention to contents with following marks in the user manual or on the product. Danger Danger: A Danger contains information which is critical for avoiding safety hazard. -
Page 8: Chapter 2 Product Information
Shenzhen Hpmont Technology Co., Ltd. Chapter 2 Product Information Chapter 2 Product Information 2.1 Nameplate Nameplate Label Name plate label is pasted on right side of the product. Its contents are shown in the following figure. MODEL: HD09-4T0P7G Product model Motor power 0.75kW... -
Page 9: Rated Value
Chapter 2 Product Information Shenzhen Hpmont Technology Co., Ltd. 2.2 Rated Value Single-phase: 200 - 240V, 50/60Hz Motor power Rated input Rated volume Rated output Size Model (kW) current (A) (kVA) current (A) Size A HD09-2S0P2G 0.25 Size A HD09-2S0P4G... -
Page 10: Chapter 3 Machenical Installation
Shenzhen Hpmont Technology Co., Ltd. Chapter 3 Machenical Installation Chapter 3 Machenical Installation • After opening the package, if damage or incompleteness is found, please do not install it and contact our distributor or us for solutions. • When conveying the inverter, please employ suitable tools according to its weight. Please avoid scratch to the product. -
Page 11: Requirement For The Installation Site
Chapter 3 Machenical Installation Shenzhen Hpmont Technology Co., Ltd. 3.2 Requirement for the Installation Site Ensure the installation site meets the following ≥100 mm requirements: • Do not install at the direct sunlight, moisture, water droplet location; • Do not install at the flammability, explosive, corrosive gas and liquid locations;... -
Page 12: Installation Of Exterior Keypad
Shenzhen Hpmont Technology Co., Ltd. Chapter 3 Machenical Installation 3.3 Installation of Exterior Keypad HD09 allows installing the optional keypad on the keypad of control door cabinet. The optional keypads are HD-LED-P and HD-LED-S. 3.3.1 Installation of HD-LED-P HD-LED-P needs a mounting base HD-KMB for installation. Firstly install the base on the keypad of control door cabinet, and then install HD-LED-P inside the base. - Page 13 Chapter 3 Machenical Installation Shenzhen Hpmont Technology Co., Ltd. To Install with Screws Install the HD-LED-P-S on the keypad of control door cabinet with screws. Dimension and mounting aperture sizes are shown in the following figure (unit: mm). 32.3 25.4 Door cabinet 16.5...
-
Page 14: Chapter 4 Electrical Installation
Shenzhen Hpmont Technology Co., Ltd. Chapter 4 Electrical Installation Chapter 4 Electrical Installation • Only qualified electrical engineer can perform wiring job. • Only when the power supply switch is completely off can you do the wiring job. • Check that the operation is effective and reliable after conneting to the emergency stop terminal of external power supply. -
Page 15: Power Terminals And Connection
Chapter 4 Electrical Installation Shenzhen Hpmont Technology Co., Ltd. 4.1 Power Terminals and Connection Power Terminal Description Terminal Description Three-phase AC power input L1, L2, L3/N Size A: terminals L2 L3/N U V W One-phase AC power input L1, L3/N... -
Page 16: Control Terminals And Connection
Shenzhen Hpmont Technology Co., Ltd. Chapter 4 Electrical Installation Power Terminal Connection Power Terminal Wiring is as shown in following figure. For selection of contactor, MCBB, power supply cable, motor cable, ground cable and braking resistor, please refer to section 5.1.1 Wiring Specifications of Input and Output, page 15. - Page 17 Chapter 4 Electrical Installation Shenzhen Hpmont Technology Co., Ltd. Terminal Description Effective with GND short circuit Digital input High frequency input (F15.03 set as No. 53 function) • Max. frequency 50.0kHz (F16.17 setting) Open collector output • External voltage 10 - 30VDC, max. current 50mA Digital output High frequency input (F15.19 set as No.
- Page 18 Shenzhen Hpmont Technology Co., Ltd. Chapter 4 Electrical Installation Analogue Input Connection HD09 HD09 Digital Input Connection Dry contact HD09 HD09 NPNconnection connection DI1 DI2 DI3 DI4 GND DI1 DI2 DI3 DI4 GND External controller Digital Output Connection HD09 HD09...
-
Page 19: External Keypad Or Upper Computer
Chapter 4 Electrical Installation Shenzhen Hpmont Technology Co., Ltd. 4.3 External Keypad or Upper Computer The RJ45 terminal can connect the optional keypad or upper computer, as shown in the following figure. Keypad or upper computer Connection RJ45 cable Definition... -
Page 20: Chapter 5 Technical Data
Shenzhen Hpmont Technology Co., Ltd. Chapter 5 Technical Data Chapter 5 Technical Data 5.1 Peripheral Accessories Selection 5.1.1 Wiring Specifications of Input and Output The AC supply to the drive must be installed with suitable protection against overload and short-circuits, i.e. MCCB (molded case circuit breaker) or equivalent device. -
Page 21: Braking Resistor
Chapter 5 Technical Data Shenzhen Hpmont Technology Co., Ltd. 5.1.2 Power Terminal Lug The wiring lugs of the power terminals (round bare terminals) can be selected according to the terminal wiring specifications, screw size, and the maximum outside diameter of the wiring lugs. -
Page 22: Technical Data
Shenzhen Hpmont Technology Co., Ltd. Chapter 5 Technical Data 5.3 Technical Data Electrical HD09-2S■P■G: single-phase 200 - 240V Inout voltage HD09-4T■P■G: three-phase 380 - 460V Fluctuating within±10%, imbalance rate<3% Input frequency 50/60Hz±5% Output voltage 0 - input voltage Output frequency... -
Page 24: Chapter 6 Keypad
Shenzhen Hpmont Technology Co., Ltd. Chapter 6 Keypad Chapter 6 Keypad HD09 can either installed with LCD display keypad (standard), or LED display keypad (optional). LCD display keypad Standard LO/RE LOCK LED display keypad Optional STOP HD-LED-P-S HD-LED-P －19－ HD09 Series User Manual V1.1... - Page 25 Chapter 6 Keypad Shenzhen Hpmont Technology Co., Ltd. Description The standard keypad contains LCD display, while the optional keypad contains LED nixie tube display. • Three status: lighting, flashing and lightless. • Do not remove the standard LCD keypad. a. Status indicator: indicating current status.
-
Page 26: Chapter 7 Troubleshooting
Shenzhen Hpmont Technology Co., Ltd. Chapter 7 Troubleshooting Chapter 7 Troubleshooting HD09 series inverter has inbuilt protective and warning self-diagnostic functions. If a fault occurs, the fault code will be displayed on the display keypad. At the same time, fault relay acts, accordingly the inverter stops output and the motor coasts to stop. - Page 27 Chapter 7 Troubleshooting Shenzhen Hpmont Technology Co., Ltd. Fault Fault reasons Counter-measures • Please check power input or the • Bus voltage is too high function of brake • E0007 Stall overvoltage The setting of stall overvoltage is • Set the value of stall overvoltage too low properly (F19.19)
- Page 28 Shenzhen Hpmont Technology Co., Ltd. Chapter 7 Troubleshooting Fault Fault reasons Counter-measures • Improper setting of V/f curve • Adjust the setting of V/f curve • Mains supply voltage is too low (F09.01 - F09.06) • Normal motor runs for a long •...
-
Page 30: Chapter 8 Parameter
Shenzhen Hpmont Technology Co., Ltd. Chapter 8 Parameter Chapter 8 Parameter Attributes are changed: “X”: It denotes that the setting of this parameter cannot be modified when the inverter is in run status. “O”: It denotes that the setting of this parameter can be modified when the inverter is in run status. - Page 31 Chapter 8 Parameter Shenzhen Hpmont Technology Co., Ltd. Ref. Code Function Setting Range Default Unit Attribute Setting 0: Not save in power off 1: Save in power off Thousands: Switch the frequency channel to the analogue selection 0: Not save...
- Page 32 Shenzhen Hpmont Technology Co., Ltd. Chapter 8 Parameter Ref. Code Function Setting Range Default Unit Attribute Setting (parameter uploading) 1/2: Current function values are copied to keypad stored parameter 1/2 F02: Run / Stop Control Parameters Start DWELL frequency ×...
- Page 33 Chapter 8 Parameter Shenzhen Hpmont Technology Co., Ltd. Ref. Code Function Setting Range Default Unit Attribute Setting 0: AI analogue feedback × F04.02 Feedback source selection 1: Terminal pulse feedback ○ F04.03 Setting digital reference 0.0 - 100.0% 0.0% 0.1% ○...
- Page 34 Shenzhen Hpmont Technology Co., Ltd. Chapter 8 Parameter Ref. Code Function Setting Range Default Unit Attribute Setting Multi-step frequency ○ F06.01 F00.09 - F00.08 5.0Hz 0.1Hz Command 2 Multi-step frequency ○ F06.02 F00.09 - F00.08 5.0Hz 0.1Hz Command 3 Multi-step frequency ○...
- Page 35 Chapter 8 Parameter Shenzhen Hpmont Technology Co., Ltd. Ref. Code Function Setting Range Default Unit Attribute Setting Compensation filtering ○ F09.10 0.01 - 10.00s 0.10s 0.01s time for motor transfer Differential compensation × F09.11 0.0 - 250.0% 200.0% 0.1% for motor differential The time constant of the ○...
- Page 36 Shenzhen Hpmont Technology Co., Ltd. Chapter 8 Parameter Ref. Code Function Setting Range Default Unit Attribute Setting 50: Clearing the counter to zero 51: Counter’s triggering signal input 53: Pulse frequency input (only DI4 AI terminal (ADI function) × F15.44...
- Page 37 Chapter 8 Parameter Shenzhen Hpmont Technology Co., Ltd. Ref. Code Function Setting Range Default Unit Attribute Setting 0: Preset operating time is disabled Preset counting value ○ F15.37 F15.38 - 9999 arriving Specified counting value ○ F15.38 0 - F15.37 arriving ×...
- Page 38 Shenzhen Hpmont Technology Co., Ltd. Chapter 8 Parameter Ref. Code Function Setting Range Default Unit Attribute Setting 1: 2400bps 2: 4800bps 3: 9600bps 4: 19200bps 5: 38400bps × F17.02 Local address 0 - 247 × F17.03 Host PC response time 0 - 1000ms 0.0 - 1000.0ms...
- Page 39 Chapter 8 Parameter Shenzhen Hpmont Technology Co., Ltd. Ref. Code Function Setting Range Default Unit Attribute Setting 15: Torque given 16: Output torque 17: Output power 18: DC bus voltage 19: Keypad potentiometer input voltage 20: AI input voltage 21: AI input voltage (after handling)
- Page 40 Shenzhen Hpmont Technology Co., Ltd. Chapter 8 Parameter Ref. Code Function Setting Range Default Unit Attribute Setting stop Instant stop function ○ F19.13 0.01 - 600.00s 5.00s 0.01s deceleration time Voltage rerise judgement time for Instantaneous loss ○ F19.14 0.00 - 10.00s 0.10s...
- Page 41 Chapter 8 Parameter Shenzhen Hpmont Technology Co., Ltd. Ref. Code Function Setting Range Default Unit Attribute Setting Ten: Unused Hundreds: The range of synthetic frequencies 0: 0 - up limitation frequency 1: Negative upper limit frequency to upper limit frequency...
- Page 42 Shenzhen Hpmont Technology Co., Ltd. Chapter 8 Parameter Ref. Code Function Setting Range Default Unit Attribute Setting E0014: Fault of current detection circuit E0016: Fault of output phase E0017: Inverter overload E0019: Motor overload E0021: Access fault of control board...
