4.18 Frequency Limit

Operation frequency can be limited by setting maximum frequency, start frequency, upper limit
frequency and lower limit frequency.
4.18.1 Frequency Limit Using Maximum Frequency and Start
Frequency
Group Code Name
19 Start frequency
dr
20 Maximum frequency Max Freq
Frequency Limit Using Maximum Frequency and Start Frequency - Setting Details
Code Description
Set the lower limit value for speed unit parameters that are expressed in Hz or
dr.19 Start Freq rpm. If an input frequency is lower than the start frequency, the parameter value
will be 0.00.
Set upper and lower frequency limits. All frequency selections are restricted to
frequencies from within the upper and lower limits.
dr.20 Max Freq
This restriction also applies when you in input a frequency reference using the
keypad.

4.18.2 Frequency Limit Using Upper and Lower Limit Frequency Values

Group Code Name
24 Frequency limit
Frequency lower limit
25
value
Ad
Frequency upper limit
26
value
LCD Display Parameter Setting Setting Range
Start Freq 0.50
60.00
LCD Display Parameter Setting Setting Range
Freq Limit 0 No
Freq Limit Lo 0.50
Maximum
Freq Limit Hi
frequency
Learning Basic Features
0.01–10.00
40.00–400.00
0–1
0.0–maximum
frequency
minimum–
maximum
frequency
Unit
Hz
Hz
Unit
-
Hz
Hz
105
