Table of Contents ............................................................................................................................................................................................... 1
2. Before using the product ......................................................................................................................................................................... 5
1. Product Overview......................................5 2. Before using the product ..................................5 3. Installation Procedure ....................................5 4. S100 Product Size (Drive with Conduit Option) ........................14 5. H100 Product Size (Drive with Conduit Option) ........................28 6. Dimensions & Screw....................................34...
Page 2
S100/H100 Conduit Option Installation Manual Thank you for purchasing LS Variable Frequency Drives! SAFETY INSTRUCTIONS To prevent injury and property damage, follow these instructions. Incorrect operation due to ignoring instructions will cause harm or damage. The seriousness of which is indicated by the following symbols.
Page 3
S100/H100 Conduit Option Installation Manual WARNING Do not remove the cover while power is applied or the unit is in operation. Otherwise, electric shock could occur. Do not run the inverter with the front cover removed. Otherwise, you may get an electric shock due to high voltage terminals or charged capacitor exposure.
Page 4
S100/H100 Conduit Option Installation Manual CAUTION Install the inverter on a non-flammable surface. Do not place flammable material nearby. Otherwise, fire could occur. Disconnect the input power if the inverter gets damaged. Otherwise, it could result in a secondary accident and fire.
S100/H100 Conduit Option Installation Manual 1. Product Overview This installation guide is applied to the LSLV – S100 / H100 drive series Conduit Option.. 2. Before using the product Perform the following tasks after receiving the conduit option. Inspect the conduit option for damage.
Page 6
S100/H100 Conduit Option Installation Manual 3.1 S100 0.4~4.0kW ① Remove the I/O cover and cable guide of the product as shown in the Figure 1. Figure 1. Remove I/O Cover and CABLE Guide ② Fasten the Conduit Option to fit on the ground terminals of the product using the prescribed bolt as shown in the Figure 2.
Page 7
S100/H100 Conduit Option Installation Manual ③ Install the I/O cover again. Figure 3. After installation 3.2 S100 5.5~22kW ① Remove the Power cover and cable guide of the product as shown in the Figure 4. Figure 4. Remove Power Cover and CABLE Guide...
Page 8
S100/H100 Conduit Option Installation Manual ② Fasten the Conduit Option to fit on the side of ground terminals of the product using the prescribed bolt as shown in the Figure 5. Figure 5. Install ③ Install the Power cover again.
Page 9
S100/H100 Conduit Option Installation Manual 3.3 S100 30~75kW ① Remove the Power cover and cable guide of the product as shown in the Figure 7. Figure 7. Remove Power Cover and CABLE Guide ② Fasten the Conduit Option to fit on the ground terminals and both ends (4points) of the product using the prescribed bolt as shown in the Figure 8.
Page 10
S100/H100 Conduit Option Installation Manual ③ Install the Power cover again. Figure 9. After installation...
Page 11
S100/H100 Conduit Option Installation Manual 3.4 H100 0.8~30kW ① Remove the Power cover and cable guide of the product as shown in the Figure 10. Figure 10. Remove Power Cover and CABLE Guide ② Fasten the Conduit Option to fit on the side of ground terminals of the product using the prescribed bolt as shown in the Figure 11.
Page 12
S100/H100 Conduit Option Installation Manual ③ Install the Power cover again. Figure 12. After installation 3.5 H100 37~90kW ① Remove the Power cover and cable guide of the product as shown in the Figure 13. Figure 13. Remove Power Cover and CABLE Guide...
Page 13
S100/H100 Conduit Option Installation Manual ② Fasten the Conduit Option to fit on the ground terminals and both ends (4points) of the product using the prescribed bolt as shown in the Figure 14. Figure 14. Install ③ Install the Power cover again.
