38ft Wave Camera Jib Crane Base Kit
(
P-W5P38-BASE)
I N S T R U C T I O N M A N U A L
All rights reserved
No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any
means, electronic, mechanical, photocopying, recording, or otherwise, except as may be expressly permitted by the
applicable copyright statutes or in writing by the Publisher.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for PROAIM P-W5P38-BASE
Summary of Contents for PROAIM P-W5P38-BASE
- Page 1 38ft Wave Camera Jib Crane Base Kit P-W5P38-BASE) I N S T R U C T I O N M A N U A L All rights reserved No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, except as may be expressly permitted by the applicable copyright statutes or in writing by the Publisher.
- Page 2 The padded shipping /storage containers has been especially designed to protect your purchase while in transit and is a good place to keep your PROAIM 38ft BASE KIT when not in use. Packaging Material of Box-1 ...
- Page 3 25x hooks Screws Please use following sequence of pictures and text in order they appear to set up your new PROAIM 38FT BASE KIT. Technical assistance is available by contacting our sales representa- tive. ASSEMBLING TRIPOD STAND Take out the Spreader from the Accessory Bag.
- Page 4 PROAIM 38ft BASE KIT Warning: We have provided double locking precautions on Jib Stand; Pin is the first and pri- mary locking, knob is the secondary locking, so first lock the Pin to avoid slipping of stand. Fix the tripod stand with Spreader and tighten the top ratchet knobs of stand to secure it in place.
- Page 5 PROAIM 38ft BASE KIT Slide in (10th) section to the rear to join the 9th section. Install the Allen screws to the join- ing holes of both the sections and tighten. Using the same approach insert 8th, 7th and remaining sections to the joints and secure via bolts as shown below.
- Page 6 PROAIM 38ft BASE KIT Attach 3 hooks one after another to four wire tensioners. Attach 2 hooks on both slots on cable guide. Then attach three extra hooks to hook attach to front side and two hooks to hook attached on back side.
- Page 7 PROAIM 38ft BASE KIT Attach 26.1ft cable to hook attached on 1st section of jib and another end with 3rd hook attached to cable guide as shown below. Then attach one end of 30.5ft cable to wire tensioner with hooks attached to 9th section and another end with 2nd hook attached on 1st section.
- Page 8 PROAIM 38ft BASE KIT Note : Install the pan tilts head. Attach one end of head cable to slot on head platform with the help of wire tensioner and another end with the cable already attached to central fork with wire tensioner as shown below.
-
Page 9: Warranty
Note: You can attach pan tilt (not included) to base of head platform through screws, bolts and nuts. YOUR PROAIM 38ft BASE KIT ALL DRESSED UP AND READY TO GO (SHOWN WITH OTPIONAL ACCESSORIES) WARRANTY We offer a one year warranty for our products from the date of purchase. - Page 10 PROAIM 38ft BASE KIT The warranty does not include, by the way of example, damage caused by products that we do- not supply or from mishandling in transit, accident, misuse, neglect, lack of care of the product , or service by anyone other than our company.
