Definition
Display Panel
Direction Down
Menu/Return/Cancel
Direction Down
Confirm Button
USB/DB9 Cover
Hard Disk Cover
Hard Disk Lock
USB
SIM
DB9
SD Card Slot
Hard Disk Box
www.en.streamax.com
Serial No.
4 Channel In / 1 Channel Out
14
Video/Audio Interface
15
16 External Announcer Interface
17
18
19
20
21
22
23
24
25 Power / Alarm Interface
7
User manual for D5 4.0
Definition
Alarm Interface
External MIC
Serial / CAN
USB
IPC
OBD
GPS Antenna
WIFI Antenna
3G/4G Interface
