1. PRODUCT CHARACTERISTICS
1.1. OVERVIEW
D5 V4.0 is superior and function-extensive MDVR model specially designed for vehicle surveillance
and remote monitoring, combined with high-speed processor and embedded operating system. The
advanced H.264 video compression and decompression, network technology, location technology and
RFIC technology make D5 to realize video record, vehicle driving information record and wireless data
upload. Combine with central software, it could help to central monitor, remote management and driving
data analysis.
In addition, D5 has passed relevant test standards of vehicle recorder, including multi-channel
signal sensors, collecting and recording vehicle status to have a real-time supervision of the vehicle and
the driver to avoid fatigue driving and speeding, reduce accidents, make sure the vehicle's security. With
the reading and analysis of data, it can provide authentic evidence for transportation department.
1.2. FEATURES
1) Standard single-din design;
2) Including RS232, RS485, USB, CAN bus interfaces.
3) Built-in speakers, card reader, LED display, battery back-up, three-axis sensor, external printer.
1.3. FUNCTIONS
1)
Local recording and video playback: 720P/WD1/D1/HD1/CIF resolution optional.
2)
Driving recording: provides statistics on speed, turning, brake, reverse, opening door, etc.
3)
Network function: supports break point uploading continually, which can realize the remote video
surveillance, video download, remote alarming and network timing of the equipment, network
setting and remote upgrade, etc.
4)
High-speed backup: support high-speed backup through USB2.0, as well as backup through SD
card.
5)
User log: on-off status of the device, video loss, recording start time / end time, user log in / log
out, modification of the device parameters, checking the time, GPS status.
6)
Import and export of the configuration file: thumb drive import/export device parameters.
7)
Device upgrade: supports local upgrade and remote upgrade.
8)
Alarm linkage: supports linkage switch value output, image display, etc.
9)
Storage formatting: formatting SD cards and external USB devices.
1.4. SPECIFICATIONS
Product Series
Input
Video
Output
Audio
Input
For more information, please visit our website
D5
4 channels WD1 + 4 channels 720P
1 channel
6 channels
4
www.en.streamax.com
User manual for D5 4.0
