3.7
Battery
Caution:
Risk of Electric Shock. Disconnect the mains power and disconnect the
device from all wiring before opening the enclosure.
The 3 V CR2032 battery is used only during power outages for real time clock and data
retention. The Mircom part number for the battery is BT-007.
Install the battery before mounting the device.
Attention: Caution – The battery used in this device may present a risk of fire or
chemical burn if mistreated. Do not disassemble, heat above 60°C
(140°F), or incinerate. Replace battery with 3-3.3 V CR2032 10 mA
maximum abnormal charging current only. Use of another battery may
present a risk of fire or explosion.
To install or replace the battery
1. Disconnect the mains power and open the mains breaker.
2. Disconnect all wiring from the unit.
3. Remove the top cover as described on page 10.
4. Disconnect the old battery.
5. Dispose of the used battery promptly. Keep away from children. Do not disassemble and
do not dispose of in fire.
6. Connect the new battery to the connector shown in Figure 4.
i
Note:
Pay attention to polarity. The positive side is on top.
Installation
15 (30)
