Y
Yi8/Yi12
Manual 1.1 en

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Yi8 and is the answer not in the manual?

Questions and answers

Related Manuals for d&b audiotechnik Yi8

Summary of Contents for d&b audiotechnik Yi8

  • Page 1 Yi8/Yi12 Manual 1.1 en...
  • Page 2 General information Yi8/Yi12 Manual Version: 1.1 en, 08/2014, D2712.EN .01 Copyright © 2014 by d&b audiotechnik GmbH; all rights reserved. Keep this manual with the product or in a safe place so that it is available for future reference. When reselling this product, hand over this manual to the new customer.

  • Page 3: Table Of Contents

    2.1. Product description............5 2.2. Connections..............6 2.3. Operation..............7 2.3.1. Controller settings............ 8 2.4. Dispersion characteristics..........9 2.5. Technical specifications..........9 Manufacturer's declarations........11 3.1. EU conformity of loudspeakers (CE symbol)... 11 3.1.1. WEEE Declaration (Disposal)....... 11 d&b Yi8/Yi12 Manual 1.1 en...

  • Page 4: Safety Precautions

    Generally speaking, a distance of 0.5 m (1.5 ft) from magnetic data carriers (floppy disks, audio and video tapes, bank cards, etc.) is sufficient; a distance of more than 1 m (3 ft) may be necessary with computer and video monitors. d&b Yi8/Yi12 Manual 1.1 en...

  • Page 5: Yi8/Yi12 Loudspeaker

    2. Yi8/Yi12 loudspeaker 2.1. Product description The Yi8 line array module is intended for small to medium sound reinforcement application. When the Y Flying frame is used, up to 24 cabinets can be flown in vertical columns producing a constant directivity dispersion pattern of 80°...

  • Page 6: Connections

    Fixed cable connection The Yi8 and Yi12 loudspeakers are each supplied with a cover plate [1] and a rubber grommet feed through [2]. For indoor operation, these items can be used to hide the connector panel, if required. For unprotected outdoor operation, the connector panel must be covered, i.e.

  • Page 7: Operation

    Yi8 and Yi12 loudspeakers. These are available in Dual Channel or Mix TOP/SUB mode. Selecting the respective Y8 or Y12 setup enables up to two Yi8 or Yi12 cabinets to be driven by the respective amplifier channel. Arc and Line setups The selection of Arc or Line depends on the curvature of the array.

  • Page 8: Controller Settings

    CUT circuit Set to CUT, the low frequency level of the cabinets is reduced. The Yi8/Yi12 array is now configured for use with the d&b Yi-SUB or J-SUB subwoofers. CPL circuit The CPL (Coupling) circuit compensates for coupling effects between the cabinets of an array.

  • Page 9: Dispersion Characteristics

    Max. sound pressure (1 m, free field) Yi8 with D80/D12/D6 139 dB/137 dB/134 dB Yi12 with D80/D12/D6 139 dB/137 dB/134 dB (SPLmax peak, pink noise test signal with crest factor of 4) Yi8 frequency response, standard and CUT modes d&b Yi8/Yi12 Manual 1.1 en...
  • Page 10 (AWG 13), 5.5 m (18 ft) Pin assignment NL4: 1+/1– Yi12 frequency response, standard and CUT modes Fixed cable (PG): Brown: (+) / Blue: (–) Weight 20 kg (44 lb) Yi8/Yi12 cabinet dimensions in mm [inch] d&b Yi8/Yi12 Manual 1.1 en...

  • Page 11: Manufacturer's Declarations

    Please dispose of this product according to the respective national regulations or contractual agreements. If there are any further questions concerning the disposal of this product, please contact d&b audiotechnik. d&b Yi8/Yi12 Manual 1.1 en...
  • Page 12 www.dbaudio.com...
