  • Page 1 Manual 5.1 en...
  • Page 2 General information M2 Manual Version: 5.1 en, 11/2016, D2092.EN .05 Copyright © 2016 by d&b audiotechnik GmbH; all rights reserved. Keep this manual with the product or in a safe place so that it is available for future reference. When reselling this product, hand over this manual to the new owner.

  • Page 3: Table Of Contents

    2.3. Operation................6 2.3.1. Controller settings..............6 2.3.2. Operation with A1............... 7 2.4. Dispersion characteristics............7 2.5. Technical specifications............8 Manufacturer's declarations........9 3.1. EU conformity of loudspeakers (CE symbol)......9 3.1.1. WEEE Declaration (Disposal)..........9 d&b M2 Manual 5.1 en...

  • Page 4: Safety Precautions

    Generally speaking, a distance of 0.5 m (1.5 ft) from magnetic data carriers (floppy disks, audio and video tapes, bank cards, etc.) is sufficient; a distance of more than 1 m (3 ft) may be necessary with computer and video monitors. d&b M2 Manual 5.1 en...

  • Page 5: M2 Loudspeaker

    2. M2 loudspeaker 2.1. Product description The M2 is a is a 2-way active high performance loudspeaker for stage monitoring purposes. The bass-reflex enclosure is optimized for minimal air compression and houses two 12" LF drivers. It is actively crossed over and powered by both channels of an appropriate d&b amplifier.

  • Page 6: Operation

    1 kHz, with the maximum attenuation below 400 Hz providing a balanced frequency response when the M2 cabinet is used in arrays of two or more. To achieve a balanced frequency response, the CPL function can be set to dB attenuation values between 0 and –9.

  • Page 7: Operation With A1

    2.3.2. Operation with A1 Two M2 cabinets can be driven by a single A1 mainframe fitted with an M2 controller module. CUT switch FREE The CUT setting is available. The characteristics of the CUT setting is described in the previous section Þ "Controller settings - CUT mode".

  • Page 8: Technical Specifications

    Nominal dispersion angle (h x v) 45° x 60° Components 2 x 12" LF driver with neodymium magnet M2 frequency response, listening position in monitor operation 1.4" exit compression driver with CD horn Measured on axis at a height of 1.7 m (5.6 ft) Connections...

  • Page 9: Manufacturer's Declarations

    Please dispose of this product according to the respective national regulations or contractual agreements. If there are any further questions concerning the disposal of this product, please contact d&b audiotechnik. d&b M2 Manual 5.1 en...
