Summary of Contents for d&b audiotechnik CCL8

  • Page 1 CCL8/CCL12 Manual 1.1 en...
  • Page 2: General Information

    Notes on document version Version 1.1: Preliminary edition. General information CCL8/CCL12 Manual - preliminary - Version: 1.1 en, 02/2025, D2780.EN .01 Copyright © 2025 by d&b audiotechnik GmbH & Co. KG; all rights reserved. Keep this document with the product or in a safe place so that it is available for future reference.
  • Page 3: Table Of Contents

    2.1  Intended use................5 2.2  Connections................6 2.3  Operation..................6 2.3.1  Controller settings..............6 2.4  Dispersion characteristics............7 2.5  Technical specifications.............. 8 Manufacturer's declarations......... 10 3.1  Conformity of loudspeakers............. 10 3.2  WEEE Declaration (Disposal)..........10 - preliminary - d&b CCL8/CCL12 Manual 1.1 en...
  • Page 4: Safety Precautions

    Generally speaking, a distance of 0.5 m (1.5 ft) from magnetic data carriers (floppy disks, audio and video tapes, bank cards, etc.) is sufficient. - preliminary - d&b CCL8/CCL12 Manual 1.1 en...
  • Page 5: Ccl8/Ccl12 Loudspeaker

    Applicable d&b amplifiers: D40|D80|D90 Product description The CCL8 is a compact cardioid line array loudspeaker for small to medium-scale sound reinforcement. When the CCL Flying frame is used, up to 24 cabinets can be flown in vertical columns producing an 80° constant directivity dispersion pattern in the horizontal plane.
  • Page 6: Connections

    CUT mode Set to CUT, the low frequency level of the cabinets is reduced. The CCL8/CCL12 cabinets are now configured for use with applicable d&b subwoofers such as the CCL-SUB. HFC function (Line/Arc setups only) Selecting the HFC (High Frequency Compensation) function...
  • Page 7: Dispersion Characteristics

    (isobars) at –6 dB and –12 dB. The nominal horizontal dispersion of 80°/ 120° is maintained over the entire operating bandwidth. CCL8 isobar diagram horizontal CCL12 isobar diagram horizontal - preliminary - d&b CCL8/CCL12 Manual 1.1 en...
  • Page 8: Technical Specifications

    78 Hz - 18 kHz Max. sound pressure (1 m, free field) CCL8 with D40/D80/D90 137 dB CCL12 with D40/D80/D90 136 dB (SPLmax: Broadband signal IEC60268) CCL8: Frequency response*, Standard and CUT modes *single cabinet within array Loudspeaker data Nominal impedance 10 ohms Power handling capacity(RMS/peak 10 ms) 400/1200 W CCL8 80°...
  • Page 9   CCL8/CCL12 cabinet dimensions in mm [inch] - preliminary - d&b CCL8/CCL12 Manual 1.1 en...
  • Page 10: Manufacturer's Declarations

    Manufacturer's declarations   3.1  Conformity of loudspeakers This declaration applies to: ▪ d&b Z0880 CCL8 loudspeaker ▪ d&b Z0882 CCL12 loudspeaker by d&b audiotechnik GmbH & Co. KG. All product variants are included, provided they correspond to the original technical version and have not been subject to any later design or electromechanical modifications.
