- Page 1 Vi7P/Vi10P Manual 1.1 en...
- Page 2 General information Vi7P/Vi10P Manual Version: 1.1 en, 08/2015, D2724.EN .01 Copyright © 2015 by d&b audiotechnik GmbH; all rights reserved. Keep this manual with the product or in a safe place so that it is available for future reference. When reselling this product, hand over this manual to the new owner.
-
Page 3: Table Of Contents
2.1. Product description..............5 2.2. Connections................5 2.3. Operation................7 2.3.1. Controller settings..............7 2.4. Dispersion characteristics............9 2.5. Technical specifications............12 Manufacturer's declarations........14 3.1. EU conformity of loudspeakers (CE symbol)....... 14 3.1.1. WEEE Declaration (Disposal)........... 14 d&b Vi7P/Vi10P Manual 1.1 en... -
Page 4: Safety Precautions
Generally speaking, a distance of 0.5 m (1.5 ft) from magnetic data carriers (floppy disks, audio and video tapes, bank cards, etc.) is sufficient; a distance of more than 1 m (3 ft) may be necessary with computer and video monitors. d&b Vi7P/Vi10P Manual 1.1 en... -
Page 5: Vi7P/Vi10P Loudspeaker
8" MF driver and a 1.4" HF compression driver with a rotatable CD horn producing a nominal dispersion (h x v) of 75° x 40° (Vi7P) or 110° x 40° (Vi10P), respectively. All components are arranged symmetrically around the center axis of the cabinet to produce a perfect symmetrical dispersion pattern. - Page 6 Fixed cable connection The Vi7P and Vi10P loudspeakers are each supplied with a cover plate [1] and a rubber grommet feed through [2]. For indoor operation, these items can be used to hide the connector panel, if required. For unprotected outdoor operation, the connector panel must be covered, i.e.
-
Page 7: Operation
For acoustic adjustment the functions CUT, HFA and CPL can be selected. CUT circuit Set to CUT, the cabinet low frequency level is reduced. The cabinets are now configured for use with actively driven d&b subwoofers. d&b Vi7P/Vi10P Manual 1.1 en... - Page 8 Positive CPL values create an adjustable low frequency boost (0 to +5 dB) at around 65 Hz and can be set when the system is used in full range mode without subwoofers. Frequency response correction of CPL circuit d&b Vi7P/Vi10P Manual 1.1 en...
-
Page 9: Dispersion Characteristics
(isobars) at –6 dB and –12 dB. Vi7P vertical setup Isobar diagram horizontal Isobar diagram vertical Vi7P horizontal setup, horn rotated Isobar diagram horizontal Isobar diagram vertical d&b Vi7P/Vi10P Manual 1.1 en... - Page 10 Vi10P vertical setup Isobar diagram horizontal Isobar diagram vertical Vi10P horizontal setup, horn rotated Isobar diagram horizontal Isobar diagram vertical d&b Vi7P/Vi10P Manual 1.1 en...
- Page 11 Make sure the gasket of the horn is in place. – Refit the horn. – Insert all screws and carefully tighten them clockwise until they fit precisely into the countersunk holes. 4. Refit the front grill. Altering the HF dispersion d&b Vi7P/Vi10P Manual 1.1 en...
-
Page 12: Technical Specifications
141 dB (SPLmax peak, pink noise test signal with crest factor of 4) Input level (100 dB /1 m) –17 dBu Vi7P frequency response, standard and CUT modes Vi7P/Vi10P loudspeaker Nominal impedance 8 ohms Power handling capacity (RMS/peak 10 ms) - Page 13 Vi7P/Vi10P cabinet dimensions in mm [inch] d&b Vi7P/Vi10P Manual 1.1 en...
-
Page 14: Manufacturer's Declarations
Please dispose of this product according to the respective national regulations or contractual agreements. If there are any further questions concerning the disposal of this product, please contact d&b audiotechnik. d&b Vi7P/Vi10P Manual 1.1 en... - Page 16 www.dbaudio.com...
