- Page 1 Y8/Y12 Manual 1.2 en...
- Page 2 General information Y8/Y12 Manual Version: 1.2 en, 10/2016, D2712.EN .01 Copyright © 2016 by d&b audiotechnik GmbH; all rights reserved. Keep this document with the product or in a safe place so that it is available for future reference. We recommend you to regularly check the d&b website for the latest version of this document.
-
Page 3: Table Of Contents
Contents Safety precautions.............. 4 1.1 Information regarding the use of loudspeakers......4 Y8/Y12 loudspeaker............5 2.1 Product description..............5 2.2 Connections................6 2.3 Operation..................6 2.3.1 Controller settings..............7 2.4 Dispersion characteristics............8 2.5 Technical specifications.............. 9 Manufacturer's declarations......... 10 3.1 EU conformity of loudspeakers (CE symbol)...... -
Page 4: Safety Precautions
Safety precautions 1.1 Information regarding the use of loudspeakers Potential risk of personal injury Never stand in the immediate vicinity of loudspeakers driven at a high level. Professional loudspeaker systems are capable of causing a sound pressure level detrimental to human health. Seemingly non-critical sound levels (from approx. -
Page 5: Y8/Y12 Loudspeaker
Y8/Y12 loudspeaker 2.1 Product description The Y8 line array module is intended for small to medium scale sound reinforcement applications. When the Y Flying frame is used, up to 24 cabinets can be flown in vertical columns producing a constant directivity dispersion pattern of 80° in the horizontal plane. -
Page 6: Connections
2.2 Connections The cabinets are fitted with a pair of NLT4 F/M connectors. All four pins of both connectors are wired in parallel. The Y8 and Y12 loudspeakers use the pin assignments 1+/1–. Pins 2+/2– are designated to actively driven subwoofers. Using the male pas s i ve c r os s over connector as the input, the female connector allows for direct... -
Page 7: Controller Settings
The transition from Line to Arc configuration within the array is made according to the splay progression but may allow for certain deviations due to the wiring of the cabinets in groups of up to two. 2.3.1 Controller settings For acoustic adjustment the functions CUT, CPL and HFC can be selected. -
Page 8: Dispersion Characteristics
2.4 Dispersion characteristics The graphs below show the horizontal dispersion angle over frequency plotted using lines of equal sound pressure (isobars) at –6 dB and –12 dB. The nominal dispersion is maintained above 600 Hz, while a useful horizontal dispersion control is achieved down to 500 Hz. -
Page 9: Technical Specifications
2.5 Technical specifications Y8/Y12 system data Frequency response (–5 dB standard) 54 Hz - 19 kHz Frequency response (–5 dB CUT mode) 100 Hz - 19 kHz Max. sound pressure (1 m, free field) with D6/10D 134 dB with D12/D20/30D 137 dB with D80 139 dB... -
Page 10: Manufacturer's Declarations
Manufacturer's declarations 3.1 EU conformity of loudspeakers (CE symbol) This declaration applies to: d&b Y8 loudspeaker, Z0707 d&b Y12 loudspeaker, Z0708 manufactured by d&b audiotechnik GmbH. All production versions of these types are included, provided they correspond to the original technical version and have not been subject to any later design or electromechanical modifications. - Page 12 www.dbaudio.com...
