Y
Yi7P/Yi10P
Manual 1.2 en

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Yi7P and is the answer not in the manual?

Questions and answers

Related Manuals for d&b audiotechnik Yi7P

Summary of Contents for d&b audiotechnik Yi7P

  • Page 1 Yi7P/Yi10P Manual 1.2 en...
  • Page 2 General information Yi7P/Yi10P Manual Version: 1.2 en, 10/2016, D2711.EN .01 Copyright © 2016 by d&b audiotechnik GmbH; all rights reserved. Keep this manual with the product or in a safe place so that it is available for future reference. When reselling this product, hand over this manual to the new owner.

  • Page 3: Table Of Contents

    2.1. Product description..............5 2.2. Connections................5 2.3. Operation................7 2.3.1. Controller settings..............7 2.4. Dispersion characteristics............8 2.5. Technical specifications............10 Manufacturer's declarations........12 3.1. EU conformity of loudspeakers (CE symbol)....... 12 3.1.1. WEEE Declaration (Disposal)........... 12 d&b Yi7P/Yi10P Manual 1.2 en...

  • Page 4: Safety Precautions

    Generally speaking, a distance of 0.5 m (1.5 ft) from magnetic data carriers (floppy disks, audio and video tapes, bank cards, etc.) is sufficient; a distance of more than 1 m (3 ft) may be necessary with computer and video monitors. d&b Yi7P/Yi10P Manual 1.2 en...

  • Page 5: Yi7P/Yi10P Loudspeaker

    Fixed cable connection The Yi7P and Yi10P loudspeakers are each supplied with a cover plate [1] and a rubber grommet feed through [2]. For indoor operation, these items can be used to hide the connector panel, if required. For unprotected outdoor operation, the connector panel must be covered, i.e.
  • Page 6 Starting with the D80 amplifier platform, the LoadMatch function enables the amplifier to electrically compensate for the properties of the loudspeaker cable used without the need for an additional sense wire. For applicable loudspeakers, LoadMatch is therefore independent of the connector type used. d&b Yi7P/Yi10P Manual 1.2 en...

  • Page 7: Operation

    Positive CPL values create an adjustable low frequency boost (0 to +5 dB) at around 65 Hz and can be set when the system is used in full range mode without subwoofers. Frequency response correction of the CPL function d&b Yi7P/Yi10P Manual 1.2 en...

  • Page 8: Dispersion Characteristics

    2.4. Dispersion characteristics Yi7P vertical setup Isobar diagram horizontal Isobar diagram vertical Yi7P horizontal setup, horn rotated Isobar diagram horizontal Isobar diagram vertical d&b Yi7P/Yi10P Manual 1.2 en...
  • Page 9 Make sure the gasket of the horn is in place. – Refit the horn. – Insert all screws and carefully tighten them clockwise until they fit precisely into the countersunk holes. 4. Refit the front grill. Altering the HF dispersion d&b Yi7P/Yi10P Manual 1.2 en...

  • Page 10: Technical Specifications

    Yi10P with D12/D20/30D 134 dB Yi10P with D80 136 dB (SPLmax peak, pink noise test signal with crest factor of 4) Yi7P frequency response, standard and CUT modes Yi7P/Yi10P loudspeaker Nominal impedance 8 ohms Power handling capacity (RMS/peak 10 ms)
  • Page 11 Yi7P/Yi10P cabinet dimensions in mm [inch] d&b Yi7P/Yi10P Manual 1.2 en...

  • Page 12: Manufacturer's Declarations

    Please dispose of this product according to the respective national regulations or contractual agreements. If there are any further questions concerning the disposal of this product, please contact d&b audiotechnik. d&b Yi7P/Yi10P Manual 1.2 en...
  • Page 14 www.dbaudio.com...
