CLEAN BURN CB-3500 Operator's Manual page 119

ITEM# PART# Description
1. 33533 BLOWER MOTOR 2HP
2. 31084 BLOWER
3. 24087 MOTOR MOUNT
4. 34072 5/16-18 STOVER TOP LOCK NUT
5. 25046 ANGLE FRONT
6. 34328 5/16-18 X 3/4 HEX HEAD FLANGE
7. 34159 1/4 X 3/4 SLOTTED IND HEX
8. 34214 1/4-20 X 1 HHCS GR-5 ZINC
9. 31225 BLOWER PULLEY 3500/5000
10. 31229 BLOWER BELT 3500 - A-BELT
11. 34116 10 X 5/8 HEX WASHER HEAD TEK Z
12. 11125 BELT GUARD ASSY
13. 31226 SHEAVE BUSHING 1"
14. 21013 1 KEY 1/4 X 1 1/4
15. 31192 REPLACEMENT BEARING PACKAGE
16. 31194 1" SHAFT W/KEYWAY (15")
17. 31238 SHEAVE BUSHING 7/8"
18. 31223 MOTOR PULLEY 3500 BLOWER
19. 31187 MOTOR MOUNT BRACKET
20. 21012 9 KEY SQ. 3/16 X 1
21. 31228 BLOWER WIRE GUARD 3500/5000
Operator's Manual: Models CB-3500 & CB-5000
ITEM#
A-17
PART# Description
• 14045 ACC BAG CB-3500, CB-5000 A.
