ICP DAS USA PCI-82x Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PCI-82x Series Cards
User Manual
Multifunction Boards
S
UPPORTS
This manual relates to the following Boards: PCI-822LU and PCI-826LU.
W
ARRANTY
All products manufactured by ICP DAS are warranted against defective materials
for a period of one year from the date of delivery to the original purchaser.
W
ARNING
ICP DAS assumes no liability for damages consequent to the use of this product.
ICP DAS reserves the right to change this manual at any time without notice. The
information furnished by ICP DAS is believed to be accurate and reliable. However,
no responsibility is assumed by ICP DAS for its use, nor for any infringements of
patents or other rights of third parties resulting from its use.
C
OPYRIGHT
Copyright © 2014 by ICP DAS. All rights are reserved.
T
RADEMARK
Names are used for identification purposes only and may be registered
trademarks of their respective companies.
C
US
ONTACT
If you have any questions, feel tree to contact us by email at:
service@icpdas.com, service.icpdas@gmail.com
We will respond to you within 2 working days.
Version 1.5, Jan. 2017
