What's in the shipping package?
The package includes the following items:
PETL-7060
Preparations for devices
1. Power Supply:+12 ~ +48 V
2. Ethernet Hub or PoE Ethernet Switch.
3. Make sure your PC has workable network settings.
4. Disable or well configure your Windows firewall and Anti-Virus
firewall first, else the "Search Servers" on page 5 may not
work. (Please contact with your system Administrator)
English/ November 2010/ Version 1.1
Software CD
DC
PETL-7060 Quick Start Guide
For PETL-7060
Quick Start Guide
(This Document)
1

Advertisement

loading

Related Manuals for ICP DAS USA PELT Series

Summary of Contents for ICP DAS USA PELT Series

  • Page 1 For PETL-7060 English/ November 2010/ Version 1.1 What’s in the shipping package? The package includes the following items: PETL-7060 Software CD Quick Start Guide (This Document) Preparations for devices 1. Power Supply:+12 ~ +48 V 2. Ethernet Hub or PoE Ethernet Switch. 3.

  • Page 2: Pin Assignments

    Pin Assignments and Wiring Note Pin Assignments Terminal Terminal Assignment Assignment RL5 COM RJ-45 RL5 NO RL4 COM RL4 NO RL3 COM RL3 NO RL2 COM RL2 NO RL1 COM RL1 NO RL0 COM DI.COM RL0 NO (R)+Vs (B)GND Digital Input/Output Wiring PETL-7060 Quick Start Guide...
  • Page 3 DI/DO Modbus Address (1xxxx) DI address: Bits per Access Begin address Points Description Range Point Type 0:Off Digital Input (0x0) 1:On Digital latched status 0:no (0x20) (high) 1:latched Digital latched status 0:no (0x40) (low) 1:latched (0xxxx) DO address: Bits Access Begin address Points Description...
  • Page 4 2. Connect both the PETL-7060 and PC to the same sub network or the same Ethernet Switch. The function of the Ethernet LED on PETL- 7000 RJ-45 is reserved (Function: N/A). 3. Apply power to the PETL-7060. The valid power voltage range is from +12 to +48 V 4.

  • Page 5: Configuring Ethernet Settings

    Configuring Ethernet Settings 1. Run the eSearch Utility. The eSearch Utility is located at: CD:\Napdos\Software\eSearch\ ftp://ftp.icpdas.com/pub/cd/6000cd/napdos/software/eSearch/ 2. Click “Search Servers” button to search your PETL-7060. 3. Double-Click your PETL-7060 to configure the settings. 2. Double-Click your PETL-7000 1. Click “Search Servers” 4.
  • Page 6 Testing your PETL-7000 Notes: In order to avoid accessing error in “IE” browser, please Notes: In order to avoid accessing error in “IE” browser, please disable your IE cache as following: disable your IE cache as following: Step 1: Click “Tools Step 1: Click “Tools”...
  • Page 7 3. Enter the password and click the “Submit” button to enter the configuration web page. (The factory default password: Admin) 4. Control the I/O for simple test. I/O Setting bit0 In the page, check the “ ” checkbox for setting ON to DO0 and Update Settings click “...

  • Page 8: Related Information

    In the Home page, check that the DO0 and DI0 status should show current status are “ON”. Related Information PETL-7060 Series Product Page: http://www.icpdas.com/products/Industrial/petl7k/petl-7060.htm PETL-7000 Series Documentations: CD:\Napdos\PETL7000\document\ http://ftp.icpdas.com.tw/pub/cd/6000cd/napdos/ptel7000/document/ PETL-7000 Series Firmware: CD:\ Napdos\PETL7000\firmware\ http://ftp.icpdas.com.tw/pub/cd/6000cd/napdos/petl7000/firmware/ NS-205, NS-205PES Product Page (optional): http://www.icpdas.com/products/Switch/industrial/ns-205.htm http://www.icpdas.com/products/Switch/industrial/ns-205pse.htm ICP DAS Web Site: http://www.icpdas.com...
