1
What's in your package?
One PCI-D64HU card
One companion PCI CD (V4.7 or later)
One Quick Start Guide (This document)
One CA-4037W cable and two CA-4002 D-Sub
connectors
1.
PCI-D64HU
2.
3.
CD
- 1 -
PCI-D64HU
Language
Version
Update
4.
Quick Start
CA-4037W
English
V1.0
Dec.2009
CA-4002
Advertisement
Related Manuals for ICP DAS USA PCI-D64HU
Summary of Contents for ICP DAS USA PCI-D64HU
- Page 1 English Language Version V1.0 Update Dec.2009 ……………………………………………… What’s in your package? One PCI-D64HU card One companion PCI CD (V4.7 or later) One Quick Start Guide (This document) One CA-4037W cable and two CA-4002 D-Sub connectors Quick Start PCI-D64HU CA-4037W CA-4002...
-
Page 2: Follow These Steps
……………………………………………… Installing Windows Driver Follow these steps: 1. Set up the Windows driver. The driver is located at: CD:\NAPDOS\PCI\PCI-D64\DLL\Driver http://ftp.icpdas.com/pub/cd/iocard/pci/napdos/pci/pci-d64/dll/driver The Windows driver only supports Windows 2000/ XP versions. 2. Click the button to start the installation. 3. Click the button to install the driver into the default folder. - Page 3 ……………………………………………… Installing Hardware on PC Follow these steps: 1. Shut down and power off your computer. 2. Remove the cover from the computer. 3. Select an unused PCI slot. 4. Carefully insert your I/O card into the PCI slot. 5. Replace the PC cover. 6.
- Page 4 ……………………………………………… Pin Assignments CON1 I_REQ I_TRG I_ACK DO15 DI15 DO14 DI14 DO13 DI13 DO12 DI12 DO11 DI11 DO10 DI10 C O N 2 N .C . N . C . N .C . O _ R E Q O _ T R G O _ A C K G N D + 5 V...
- Page 5 ……………………………………………… Self Test 1. Use the CA-3710 to connect the CON1 on board to DN-37 wiring terminal board (Optional). 2. Connect the DI (0~15) with DO (0~15). DI0 with DO0 ... DI15 with DO15 CON2 CON1 CA-3710 DN-37 I/O Wiring 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 10 11 12 13 14 15 16 17 18 19 - 5 -...
- Page 6 3. Execute the DIO sample program. The sample program is contained in zip file which is located at: CD:\NAPDOS\PCI\PCI-D64\DLL\Demo 4. Test DIO (0~15) function and get to test result. ※ The DI (16~31) do not connect to DO (16~31), wherefore channel 16~31 show high status (Red light).
- Page 7 ……………………………………………… Additional Information PCI-D64HU Card product page: http://www.icpdas.com/products/DAQ/pc_based/pci-d64hu.htm CN-37 wiring terminal board (Optional) page: http://www.icpdas.com/products/DAQ/screw_terminal/dn_37.htm CA-3710(Optional) cable page: http://www.icpdas.com/products/Accessories/cable/cable_selection.htm Documentation: CD:\NAPDOS\PCI\PCI-D64\manual CD:\NAPDOS\PCI\manual http://ftp.icpdas.com/pub/cd/iocard/pci/napdos/pci/pci-d64/manual/ Software: CD:\NAPDOS\PCI\PCI-D64\ http://ftp.icpdas.com/pub/cd/iocard/pci/napdos/pci/pci-d64/dll/ The ICP DAS Web Site http://www.icpdas.com Technical support Supplies and ordering information Information related to upgrades, new...
