7.2 Network/ Power Unit (NPU)

46
1.
HomePNA 2.0 interface, a standard phone jack (RJ-11)
2.
Ethernet interface, a standard 10/100 BaseT Ethernet jack (RJ-45)
3.
Router outdoor unit connection: A multiwire cable from Router unit
is connected to this.
The connector is a punch down connector inside the unit.
3
2
1
Nokia RoofTop™ Wireless Router Installation Guide
