Network Interface & Power Supply Unit
Front Panel
Your network interface and power supply unit has LEDs which indicate the functioning of
your unit. If you are experiencing problems with your wireless router, call your Internet
Service Provider' s (ISP' s) service desk. The service personnel may ask you to refer to the
LEDs on the network interface and power supply unit. When you call, make sure you can see
the LEDs to be able to give the information to the service personnel.
1. PWR/ LAN - shows the local area network activity and that the unit power is "ON"
2. Anchor: - shows the status in the network and gives wireless link information; if this
light is off you may not have a connection to the internet
1. PWR/ LAN
2. Anchor
3. Network
