3. Network
Bottom Panel Connections
3
1. HomePNA 2.0 interface: A standard phone jack (RJ-11)
2. Ethernet interface: A standard 10/100 BaseT Ethernet jack (RJ-45)
3. Router outdoor unit connection : This connector connects directly to your
Connecting the Wireless Router to Your PC, LAN or Home PNA
Your wireless router is capable of providing internet access for a single PC via a direct
connection or to multiple PCs via Local Area Network (LAN) or via Home PNA.
2
1
Bottom Panel Connections
outdoor wireless router.
