Polycom® SpectraLink® 6020 Wireless Handset User Guide
Indicator Function
Normal
The muted position is shared with the noise mode currently set either by using the
softkey in the standby mode or through the
High
Select Normal for most office environments; High for moderate background noise; or Severe
Severe
for extremely noisy conditions. If you use High or Severe modes in a quiet environment, the
person on the other end of the line may find it difficult to hear your voice.
Locked
Locked indicates that the keypad is locked to prevent accidental activation. Press the
softkey and then the # key to unlock it.
The download icon indicates that the handset is downloading code. This icon only appears
while the handset is running the over-the-air downloader. It appears to the right of the signal
strength icon in the same location as the voicemail icon.
The download failure icon indicates that the handset has failed to download code because the
code is incompatible with the handset hardware. Contact your system administrator should
this icon appear.

Softkey Labels

The bottom row of the handset displays labels associated with the four softkeys just below it. When a
softkey is active, a label appears to describe its function. Pressing the softkey will activate the feature.
Label Description
Back Go back
CAPS/caps Change case
Cfg Configure
Clr Clear
Cncl Cancel
Del Delete
Exit Exit
Hold Hold
Mute Mute
No Negative reply
Nois Noise mode
Play Play
Prof Profile
Spkr Speakerphone
Unlk Unlock keys
Yes Positive reply
October, 2011 | 1725-36729-001_D.docx
Action
Returns to the previous menu display.
Toggles to allow a change in case when entering alphabetical text.
Opens the Config Menu.
Deletes the entry.
Returns to the previous menu display without saving any data that might
have been entered.
Deletes the character to the left of the cursor.
Exits out of the menus.
Places a call on hold.
Toggles to mute or unmute the microphone.
Press to reply "No" to a displayed question.
Allows you to select the appropriate noise mode for the environment.
Plays the selected ring tone.
Opens the Profile menu.
Toggles speakerphone function.
Press Unlk, then the # key to unlock a locked keypad.
Press to reply "Yes" to a displayed question.
Config
menu.
Nois
Unlk
8
