1.4

Status LEDs

The status LEDs on the Level Sense Pro provide a visual indication
of the control state. The below table is a system status guide.
Color /LED
Power
Connected
Cloud
Calibrate
Calibrated
Alarm
No Alarms
1.5

Wiring Panel

USER
Wiring of sensors (level, leak and float switch) have no polarity.
To connect sensors, turn the terminal screw counterclockwise to
open the wiring clamp. Insert wire into the clamp and turn
terminal screw clockwise to close clamp on wire.
Tighten until wire is firmly secured.
Blue Yellow
AC Power No AC
Good Power
Flash:
Connecting
to Wi-Fi Solid: WPS
Mode
Learning
Level
LEVEL ALARM
SENSOR NC COM NO
Red
No AC Power
Low Battery
Wrong
Password
Or out-of-
range
—
—
Active Alarm
LEAK FLOAT
SENSOR SWITCH
White
—
Hotspot
Mode
—
—
DC
RESET
3
