1.0 About Level Sense Pro

Level Sense Pro is a Wi-Fi based residential environmental
monitor designed specifically for the home owner who wants to
keep a watchful eye on their property at all times. Level Sense
Pro monitors five critical elements of the home as alarm inputs—
sustained power loss, sump pit high water level, water leak(s),
temperature and humidity levels.
Each of the five alarm inputs can be configured individually as
alarm triggers based on their state or level. There are three alarm
outputs of the Level Sense Pro; email/SMS (text message), audible
siren and alarm relay contacts. Additional detail of the alarm
outputs can be found in the alarm outputs section of the manual.
Please read the User Manual carefully before using the Level
Sense Pro.
1.1

Device Specifications

Operating Temperature: 32-122 F° (0-50 C°)
Operating Humidity: 0-95% RH, non-condensing
Input Power: 12VDC 700mA
Battery: 3.7V Lithium Ion Polymer 1100mAH *Read Battery Warning
Siren: 90db *Estimated
Antenna: Internally integrated
Sensor Inputs: 2x Dry contact
Relay Contact: 48VDC 1Amp Max
Dimensions: 5x6x1.25"
Weight: 2lbs
Contains FCC ID: 2AC7Z-ESP8266EX
1.2

Requirements

120 VAC Power outlet
Wi-Fi internet within range of Level Sense
Wi-Fi device with web browsing
Screw Driver, flat head #3 or #4
