Summary of Contents for Level Sense Freezer Sentry
- Page 1 FREEZER SENTRY User Manual www.level-sense.com...
-
Page 2: Table Of Contents
F R E E Z E R S E N T R Y U S E R M A N U A L TABLE OF CONTENTS Section 1: About Freezer Sentry................. Section 2: Speci�cations....................Section 3: Requirements....................Section 4: In the box....................... -
Page 3: About Freezer Sentry
• Optional Sensor Inputs for Leak Sensor & Float Switch Each of the above-mentioned alarm inputs can be configured individually as alarm triggers based on their state. There are three alarm outputs of the Freezer Sentry • SMS (Text Message) •... -
Page 4: Requirements
SECTION 3: REQUIREMENTS • 120/240 VAC (50 or 60 Hz) Power Outlet • 2.4 Ghz Wi-Fi internet within range of Freezer Sentry • Wi-Fi enabled device with Web browsing • Flat head screwdriver #3 or #4 (if optional leak or float sensors are used) SECTION 4: IN THE BOX 1. -
Page 5: Account Creation
SECTION 5: ACCOUNT CREATION 1. Level Sense Account Creation: Thank you for your Level Sense Freezer Sentry purchase. The first step in getting your Freezer Sentry device online is to create your Level Sense Account. This can be done with either a computer, or a smartphone/tablet. - Page 6 Next click on the register button and enter in your personal information into the register page, and lastly click the create button. Congratulations, your Level Sense account has been created. The Username and Password that are used for your account are the same for both the mobile application and the website.
-
Page 7: Status Leds
SECTION 6: STATUS LEDS The status LEDs on the Freezer Sentry provides a visual indication of the state of the Freezer Sentry. The below table is a system status guide. PLEASE NOTE that if the four LEDs are flashing in unison, then this is a CLAIM CODE. If you have a claim code, reference Section 9. -
Page 8: Installation
1. Head Unit Installation: a. The head Unit can be mounted in one of three ways. i. Magnetically: Magnets are mounted inside of the Freezer Sentry enclosure. Place the back of the enclosure onto the side of the refrigerator/freezer, and the head unit will stay in place thanks to the magnets. - Page 9 If not already done, the temperature sensor can be inserted gently into the Level Sense (LS) Freezer Sentry head unit as shown below. Follow the labels on the printed circuit board which will assist with inserting the sensor. There is a Green LED that will light up on both ends of the temperature sensor when the board is inserted correctly, and when power is applied.
- Page 10 F R E E Z E R S E N T R Y U S E R M A N U A L b. The Temperature sensor can be installed in the refigerator/freezer one of three ways. i. 1. The integrated hook can be used to mount the sensor on a wire rack as ii.
-
Page 11: Connect To Wi-Fi
SECTION 8: CONNECT TO WI-FI The Freezer Sentry device is immediately ready to join your 2.4 Ghz Wi-Fi network after power up. When the Freezer Sentry has not been configured to a Wi-Fi network the Cloud LED will display as WHITE, and the access point is active (the unit will broadcast its Level Sense Wireless Network. - Page 12 F R E E Z E R S E N T R Y U S E R M A N U A L 1. Hotspot Method: a. To connect your Freezer Sentry to your Wi-Fi network via the hotspot mode, you will need a Wi-Fi enabled device like a smartphone or laptop. The Cloud LED of the Freezer Sentry should be white which indicates the device is broadcasting a Wi-Fi hotspot.
- Page 13 NOT be presented with a claim code). Lastly, press the submit button. e. The webpage then instructs you to click the RESET button on the Freezer Sentry. After restarting, the Cloud LED will pulse yellow until it connects to your Wi-Fi.
-
Page 14: Section 9
If you did not enter your E-Mail address on the Wi-Fi configuration page, it will be necessary to claim the device. Once the Freezer Sentry is connected to your wireless network, the Freezer Sentry will flash all four LEDs in unison. This is a claim code. -
Page 15: Section 11
For example, if your current temperature reading from the Freezer Sentry device is 34F, and the actual temperature in the freezer is 32F, then you will enter 2.00 into the first text box and select the minus sign into the operation text box to adjust the temperature reading to the correct temperature value. - Page 16 F R E E Z E R S E N T R Y U S E R M A N U A L 2. The second input listed is the humidity sensor. The left side of the screen has the lower set point, and the right side is the upper set point. A humidity reading below the lower setpoint will put the device into alarm state.
-
Page 17: Viewing Data
SECTION 13: WI-FI PASSWORD RESET To clear the Wi-Fi credentials from the Freezer Sentry, complete the following steps: • Press and hold the SILENCE button until all four LEDs appear as RED. • Let go of the SILENCE button, and then click the SILENEC button two times, two LEDS will remain lit. -
Page 18: Service Disclaimer
Continued service may be offered monthly or annually for a fee or gratis. Level Sense reserves the right to alter, amend or change information, services, and pricing at any time. Level Sense also reserves the right to modify or discontinue services at any time after the first year. - Page 19 F R E E Z E R S E N T R Y U S E R M A N U A L 1. Warrantor: in this warranty, warrantor shall mean “dealer, distributor, and/or manufacturer.” 2. Elements of warranty: this product is warranted to be free from defects in materials and craftsmanship with only the limitations and exclusions set out below.
- Page 20 F R E E Z E R S E N T R Y U S E R M A N U A L interruption losses, lost profits, loss of business, loss of data or information, or financial loss, for claims of any nature, including but not limited to claims in contract, breach of warranty or tort, and whether or not caused by warrantors’...
- Page 21 F R E E Z E R S E N T R Y U S E R M A N U A L Exclusive warranty: the limited warranty or warranties described herein constitute the sole warranty or warranties to the purchaser. All implied warranties are expressly disclaimed, including: the warranty of merchantability and the warranty of fitness for a particular use and the warranty of fitness for a particular purpose and the warranty of non-infringement and/or any warranty arising from a course of...
- Page 22 F R E E Z E R S E N T R Y U S E R M A N U A L same duration as the applicable written warranty or warranties herein. The warranty or warranties herein may give you specific legal rights that will depend upon the applicable law.
- Page 23 Effective date 01/01/2022 Sump Alarm, Inc. d.b.a. Level Sense Phone: 314-787-8059 www.level-sense.com...
