Control Terminal Block
Control Wiring Block Diagram
Relay N.O.
R1
Relay Common
R2
Relay N.C.
R3
R1 R2 R3
30V DC
Resistive 3.0A
Inductive 0.5A
See Control Wiring Block Diagram Notes on next page.
HongKong|UK|China
www.aotewell.com
(6)
Enable Jumper
SNK
30V DC
50mA
Non-inductive
Analog Output Select
0-10V
0-20mA
SNK
SRC
125V AC 240V AC
3.0A 3.0A
0.5A 0.5A
sales@aotewell.com
01
02
03
SRC
04
05
06
07
08
09
+24V
11
+10V
12
13
14
15
0-10V
16
0/4-20mA
17
18
19
(4)
+ / - 10V
10V
01 02 03 04 05 06 07 08 09
11 12 13 14 15 16 17 18 19
(1)
Industry Automation
Typical
(1)(6)
SRC Wiring
Stop
(2)
Start/Run FWD
(3)
Direction/Run REV
Digital Common
Digital Input 1
Digital Input 2
Digital Input 3
Digital Input 4
Opto Common
+24V DC
+10V DC
(4)
0-10V (or ±10V) Input
Analog Common
4-20mA Input
Analog Output
Opto Output 1
Opto Output 2
RS485 Shield
Voltage Range Select
(6)
Enable
ENBL
Jumper
+86-755-8660-6182
Typical
SNK Wiring
Pot must be
1-10k ohm
2 Watt Min.
(5)
Common
24V
RS485
(DSI)
1
