Installing SoundPoint

This section provides basic installation
instructions and information for obtaining
the best performance with the Sound-
®
Point IP 300/301 SIP phone. If you re-
quire additional information or assistance
with your new phone, please contact your
system administrator.

Connecting Network and Power Source

AC Power Option
Connect the supplied Network Cable
between the LAN jack on the phone and
the LAN port on the wall or hub/switch
device port. Connect the DC plug of the
AC wall adapter into the supplied LAN
cable as shown.
Power over Ethernet (PoE) Option
Using an Inline Power Cable (optional acces-
sory from Polycom), the phone can be alter-
nately powered from a Power over Ethernet
(PoE) compliant switch or hub. Inline Power
Cables exist for both IEEE 802.3af and Cisco
pre-standard PoE options. Plug the keyed end
of the Inline Power Cable into the LAN jack
on the phone and the other end to an available
port on the POE switch or hub.
Cisco™Catalyst™ In-Line
Power Switch
IEEE 802.3af compliant
In-Line Power switch

IP 300/301 SIP

®
The SoundPoint
Guide includes regulatory compliance
information that your system administrator
should review and can also be found at:
www.polycom.com
2
®
IP 300/301 SIP User
Cisco™ In-Line Power
Cable
(Part No. 2200-11014-002 Rev A)
OR
IEEE 802.3af In-Line
Power Cable
(Part No. 2200-11077-002 Rev A)
