Foscam FI9928P Quick Setup Manual

Quick Setup Guide
HD Wireless PTZ Dome IP Camera
Model: FI9928P
To view this guide in other languages (e.g. Nederlands,
Deutsch, Français, Español), and for detailed manuals, tools,
etc., please visit http://www.foscam.com > Support > V1.0.1
Download Center.
EQ992801
Setting Up Your Foscam
Security Camera
A
Getting Started
Package Contents
IP Camera Power Adapter Resource CD
Quick Setup Guide
WARRANTY CARD
HD Wireless PTZ Dome IP Camera
Model: FI9928P ~~~~~~~~~~~~~~~~~~~~~~
~~~~~~~~~~~~~~~~~~~~~~
~~~~~~~~~~~~~~~~~~~~~~
~~~~~~~~~~
~~~~~~~~~~~~~~~~~~~~~~
~~~~~~~~~~~~~~~~~~~~~~
~~~~~~~~~~~~~~~~~~~~~~
~~~~~~~~~~
Quick Setup Guide Wi-Fi Antenna Warranty Card
Security Tips
Please change the password of your camera regularly, using a
combination of numbers, letters and special characters.
We recommend that you regularly update your camera to the
latest available software and rmware versions to help ensure
the best experience for your camera.
B
Physical Description
Antenna
LAN
Audio In/Out
LENS
Power
Infrared LED
Alarm In/Out
SD Card Reset Button and the Indicator
C
Setting Up Your Camera:
Wired Connection via Foscam App
(Recommended)
Router
WPS WPS
Note: We highly recommend that you first begin the setup process
by connecting your camera to your Internet router with an
Ethernet cable. After setup is successful, you'll be able to unplug
the cable and login to your wireless network for WiFi operability.
Minimum Requirements:
To help ensure a smoother video experience on the smartphone, it's
recommended that your smartphone has the following:
IOS: version 8.1 or higher.
Android: 4.1 or higher, using a device with a Graphics Processing Unit
(GPU) function.
Camera Setup Steps:
1. Please mount the antenna and make sure it is in a vertical upright
position.
2. Connect the camera to your Internet router using an Ethernet cable.
3. Connect the power adapter to the camera, and wait for a few moments
until the camera alerts you that the "Wired connection succeeded" (if
the device is connected with the audio output device).
4. From your smartphone, search for "Foscam" via the App Store or
Google Play Store. Download, install and open the App to begin
con guration.
5. Under "My Cameras, " select "Tap + to add new camera" and then scan
the QR code, which is located on your camera (see illustrations below).
My Cameras < Scan
Tap + to add new camera
Tap + button Scan the QR code which is
located on your camera.
6. On the "Which way to choose" screen, con rm that "Wired" is selected
(upper-left corner) and tap "Ready. " Wait a few moments for a message
con rming that the setup process has been completed (see illustra-
tions below).
Complete
< Which way to choose
Wired Wi-Fi
Congratulations!
Successfully added!
Ready
Con rm "Wired" and Connection succeeded!
then tap "Ready"
