Specifications - Icom IC-V8000 Service Manual

SECTION 1
' ' GENERAL
• Frequency coverage
• Type of emission
• Frequency stability
• Tuning steps
• Antnna connector
• Power supply requirement
(negative ground)
• Number of memory channel
• Call channel
• Scanning mode
• Current drain (approx.)
• Usable temperature range
• Dimensions (projections not included)
• Weight
' ' TRANSMITTER
• RF output power (at 13.8 V DC)
• Modulation system
• Maximum frequency deviation
• Spurious emissions
• Microphone connector
' ' RECEIVER
• Receive system
• Intermediate frequencies
• Sensitivity
• Squelch sensitivity
• Selectivity
• Spurious and image rejection
• Audio output power (at 7.2 V DC)
• Ext. speaker connector
*[USA] version only
All stated specifications are subject to change without notice or obligation.

SPECIFICATIONS

:
Version
[USA]
[SEA]
[CSA]
*Specifications Guaranteed: 144–148 MHz only
: FM (F2D / F3E)
: ± 10 ppm (–10˚C to +60˚C; +14˚F to +140˚F)
: 5, 10, 12.5, 15, 20, 25, 30 or 50 kHz
: SO-239 (50 Ω)
: 13.8 V DC (Operable voltage range: 11.7 to 15.9 V)
: 207 channels (including 6 scan edges and 1 call channel)
: 1 channel
: Full, Program, Priority, Memory, Channel, Skip, Tone, DTCS, Bank and WX
:
Transmit
Receiving
: –10˚C to +60˚C; +14˚F to +140˚F
: 150(W) 50(H)
: 1.09 kg; 12.3 oz.; 38.4 oz
: 75 W / 25 W / 10 W / 5 W (High / Middle High / Middle Low / Low)
: Variable reactance frequency modulation
: Narrow: ±2.5 kHz*; Wide: ±5.0 kHz
: Less than –60 dB
: 8-pins modular (600 Ω)
: Double conversion superheterodyne system
: 1st
2nd
: 0.15 µV at 12 dB SINAD (typical)
: 0.08 µV at threshold (typical)
: Narrow; More than ±3.0 kHz at –6 dB, Less than ±9.0 kHz at –55 dB*
Wide; More than ±6.0 kHz at –6 dB, Less than ±14.0 kHz at –60 dB
: 60 dB (typical)
: More than 2.0 W at 10% distortion with an 8 Ω load
: 3-conductor 3.5(d) mm (
Receive
136.000–174.000 MHz*
High (75 W)
Middle High (25 W)
Middle Low (10 W)
Low (5 W)
Max. audio
Stand-by
150(D) mm; 5 29 ⁄
32
21.7 MHz
450 kHz
")/8 Ω
1
⁄
8
1 - 1
Transmit
144.000–148.000 MHz
140.000–150.000 MHz*
136.000–174.000 MHz*
15 A
9.0 A
6.0 A
5.0 A
1.0 A
0.8 A
(W) 1 31 ⁄ (H) 5 29 ⁄ (D) in.
32 32
