SECTION 7

SEMI-CONDUCTOR INFORMATION

•
TRANSISTOR AND FET'S
2SA1576 R 2SA1734
(Symbol: FR) (Symbol: LB)
B
B
C
C
E
E
2SC3356 2SC4116 BL
(Symbol: R22) (Symbol: LL)
B B
C
C
E
E
2SC4406 4 2SC4684 (LB)
(Symbol: JT) (Symbol: 2-7B2A)
C
B
C
E
B
E
3SK272 DTA113 ZU
(Symbol: K) (Symbol: 111)
B
G1 S
C
G2 D
E
DTB113 ZK DTC114 EU
(Symbol: G11) (Symbol: 24)
B
B
C C
E
E
RD70HVF1 XP4601
(Symbol: RD70HVF1) (Symbol: 5C)
D
D
E1 C1
S G
B1 B2
C2 E2
S
G
2SA1586 GR 2SB1132 R 2SC2712 BL
(Symbol: S0) (Symbol: BARB) (Symbol: L0)
B
B
C
C
E
E
2SC4116 GR 2SC4213 B 2SC4226 R25
(Symbol: LG) (Symbol: AB) (Symbol: R25)
B
C
E
2SK1069 4 2SK3074 2SK3075
(Symbol: FJ) (Symbol: UW) (Symbol: UB F)
G
S
G S
D
D
DTA114 EU DTA143 TUA DTA144 EU
(Symbol: 16 ) (Symbol: 93) (Symbol: 16)
B B
C C
E
E
DTC143 ZU DTC144 EU DTC144 TU
(Symbol: 123) (Symbol: 26) (Symbol: 06)
B B
C C
E E
7 - 1
•
DIODES
1SS133 1SS355
(Symbol: Yellow line) (Symbol: A)
yellow
B
C
E
HVC350B HVC375B
(Symbol: BO) (Symbol: B8 )
B
C
E
MA2S728 MA742
(Symbol: B) (Symbol: M1U)
S
G D
MA8091 M RD20E B2
(Symbol: 9-1) (Symbol: 202)
B
C
E
B
C
E
DA221
DAN222
(Symbol: K) (Symbol: N)
A C A1
A2
HVC376B HVU131TRF
(Symbol: B9 )
(Symbol: P1)
MA77 MA8056M
(Symbol: 4B) (Symbol: 5-6)
A C
XB15A308 XB15A407
(Symbol: T8) (Symbol: None)
K
A
DSA3A1
(Symbol: )
green
C
MA2S111
(Symbol: A)
MA8075 L
(Symbol: 7-5)
