6-2 HM-133V
[CHASSIS PARTS]
REF. NO. ORDER NO. DESCRIPTION
W1 8900010450 Cable OPC-153
MP1 8210018830 2539 Front panel
8210018890 2539 Front panel (A)
8210018910 2539 Front panel (B)
MP2 8210018840 2539 Rear panel
MP3 8930057380 2539 PTT button
MP4 8930057390 2539 LED lens
MP5 8930057570 SW rubber
MP6 8930057520 2539 Keyboard
8930057710 2539 Keyboard (A)
8930057700 2539 Keyboard (B)
MP8 8810009370 Screw B0 M3 x 12 ZK (BT)
MP9 8810009560 Screw B0 M2 x 6 ZK (BT)
MP3 (C)
[MAIN UNIT]
REF. NO. ORDER NO.
DESCRIPTION
QTY.
MC1 7700002310 Microphone EM-140
1
1
Screw abbreviations B0, BT: Self-tapping
1
ZK: Black
1
1
1
2
1
1
1
1
2
3
MP6 (C)
MP1 (C)
MP5 (C)
MP4 (C)
QTY.
1
MP2 (C)
MP9 (C)
MAIN unit
MC1 (M)
HM-133V
UNIT abbreviations (C): CHASSIS PARTS
(M): MAIN UNIT
MP8 (C)
MP9 (C)
6 - 3
W1 (C)
